C93200 SAE660 RG7 Cast Bronze Bearings Spacer Alloy Leaded Tin Bronze Bushing Metal Graphite
C93200 SAE660 RG7 Bronze Spacer Alloy Leaded Tin Bronze Bushing Metal Graphite
CDA Copper, Brass, and Bronze Alloys Bearing & Bushings. BRONZE BEARINGS COMPOSITION
Bronze Bearing Wheel C93200 (SAE 660 RG7) Bronze Bushing & Spacer- Metal Graphite Bearing Plain Bearing Components PN RG7 DIN CuSn7Zn4Pb7
SAE 660 Bushing ISO CuSn7Pb7Zn4 CuSn7 DIN 1705 RG 7 Bronze Bearing Cast Bronze Sleeve Bushing
C93200 Leaded Tin bronzes C93200 (SAE 660 RG7) Leaded Tin Bronze is considered the "standard" bearing material for light duty. The alloy has excellent machining properties, good hardness, strength and wear resistance with excellent antifriction qualities.
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS UNLESS OTHERWISE SPECIFIED.INCH SIZE ALSO AVAILABLE.
2. REMOVE SHARP EDGES.
3. AVOID WELDING SPATTERS, REMOVE IF ANY
4.MACHINING TOLERANCE
C93200 Leaded Tin Bronzes Bushing
Chemical Composition
|
Cu%1 |
Pb% |
Sn% |
Zn% |
Fe% |
P%2 |
Ni%3 |
Al% |
S% |
Sb% |
Si% |
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| Chemical Composition according to ASTM B505/B505M-18 | |||||||||||
| 81.00- 85.00 |
6.00- 8.00 |
6.30- 7.50 |
1.00- 4.00 |
0.20 |
0.15 |
1.00 |
0.005 |
0.08 |
0.35 |
0.005 |
|
Similar or Equivalent Specification
|
CDA |
ASTM |
Asarcon |
SAE |
AMS |
Federal |
Military |
Other |
|---|---|---|---|---|---|---|---|
| C93200 | B505 B505M B144-3B |
77 | 660 J461 J462 |
QQ-C-390, E7; QQ-B-1005, COMP 12 |
MIL-B-11553, COMP 12 | Bearing Bronze |
C93200 (SAE660) Bearing Bronze / C932 Bearing Bronze
Typical Uses
AUTOMOTIVE: automotive fittings
FASTENERS: washers
INDUSTRIAL: thrust washers, pumps, bushings, machine parts, sliding bearings, pump bushings, hydraulic bushes, insert bearings, bearings.
ZHEJIANG TOP BEARINGS CO., LIMITED one of the professional sae 660 bushing iso cusn7pb7zn4 cusn7 din 1705 rg 7 bronze bearing cast bronze sleeve bushing manufacturers, is also known as an excellent supplier in China. We now bring you the best quality sae 660 bushing iso cusn7pb7zn4 cusn7 din 1705 rg 7 bronze bearing cast bronze sleeve bushing with high precision and reliable performance. Should you are interested in it, please feel free to get in touch with our factory.
