China High Voltage Transmission Lines Galvanized Wire Cable Increase The Tensile Force for sale

High Voltage Transmission Lines Galvanized Wire Cable Increase The Tensile Force

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 10 days after confirmed order or as per order quantity

Brand: Litong Global

Product Description

Anhui Litong Rare-earth Steel Cable Co.,Ltd is a company to produce and export different types of Galvanized steel wire for electricity and communication.

Features

Using advanced galvanization technologies to produce Smooth and Uniform heavy coatings to extend the service life of products_.
Using Water-heavy drawing machines to draw wires to keep best raw material’s mechanical properties ,therefore our products have better flexibilities and stable functions

Applications

Our Galvanized Steel Wire /strand is used for guy wire ,telegraph pole, farming purposes, and optical cables, guy wire, ground wire(stay wire),Steel Core for ACSR Conductor, barrier cables, messenger wires.

Grade	Dia. (mm)	Tensile Strength Not less (Mpa)	Stress at elongation of 1% Not less (Mpa)	Elongation L0=250mm Not less	Torsion Not less Times/360°	Mandrel Dia
Grade	≥1.24-2.25	1340	1170	3.0	16	1
Normal	≥2.25-2.75	1310	1140	3.0	16	1
	≥2.75-3.00	1310	1140	3.5	16	1
	≥3.00-3.50	1290	1100	3.5	14	1
	≥3.5-4.25	1290	1100	4.0	12	1
	≥4.25-4.75	1290	1100	4.0	12	1
	≥4.75-5.5	1290	1100	4.0	12	1
High	≥1.24-2.25	1450	1310	2.5	16	1
	≥2.25-2.75	1410	1280	2.5	16	1
	≥2.75-3.00	1410	1280	3.0	16	1
	≥3.00-3.50	1410	1280	3.0	14	1
	≥3.5-4.25	1380	1240	3.0	12	1
	≥4.25-4.75	1380	1170	3.0	12	1
	≥4.75-5.5	1380	1170	3.0	12	1
Extra- High	≥1.24-2.25	1620	1450	2.0	14	1
	≥2.25-2.75	1590	1410	2.0	14	1
	≥2.75-3.00	1590	1410	2.5	12	1
	≥3.00-3.50	1550	1380	2.5	12	1
	≥3.5-4.25	1520	1340	2.5	10	1
	≥4.25-4.75	1520	1340	2.5	10	1
	≥4.75-5.5	1520	1270	2.5	10	1
