Hard Drawn High Tensile Galvanized Steel Wire Strand ASTM A 475 For Telecom Mission
Galvanized Steel Wire/Strand
Our range of Galvanized Steel Wire/Strand(called”steel wire) has been designed for superior efficiency and performance.Steel Wire manufacturing has been Litong Cable’s initial products since established factory in 2000.It has today evolved into the country’s main larger player with a domestic share of over 15% ,esp.in China State Grid and an installed capacoty of over10,000MT.The Main product range comprises of 7 strand and 19 strand.
Product Range
Our Galvanized Steel Wire &Strand include:
.Main Single Wire Size:1.0mm-4.8mm
.Structure of Strand:1*7 &1*19
.Main Production Standard:ASTM B 498,IEC888,GB/T3428, YB(T)13-83,ASTM B 80,ASTM B 500 ,ASTM A 475,BS183,YB/T5004,GB/T-20492,ASTM B 803,ASTM A 640 etc.
Application:ACSR Conductor,Telecommission,Guy Wire,Messenger,Overhead transmission,stay wire,etc.
Approvals,Certifications and Testing
.ISO9001-2008 Certified
.SGS-Tested
.NMCI-Tested
.CANS-Certified
Galvanized Steel Wire Strand as per ASTM A 475
|
Type |
1x7 |
Type |
|
1x19 |
|||||||||
|
Nominal Diameter |
Nominal Area |
Min.Breaking Strength(MPA) |
Nominal Diameter |
|
Nominal Area |
Min.Breaking Strength(MPA) |
|||||||
|
Single Wire Dia. |
Strand Wire Dia. |
1270 |
1370 |
1470 |
1570 |
Single Wire Dia. |
Strand Wire Dia. |
1270 |
1370 |
1470 |
1570 |
||
|
mm |
Mm2 |
Min. Breaking Load(KN) |
mm |
Mm2 |
Min. Breaking Load(KN) |
||||||||
|
1.6 |
4.8 |
14.07 |
16.40 |
17.70 |
19.00 |
20.80 |
1.6 |
8.0 |
38.20 |
43.6 |
47.10 |
50.50 |
53.90 |
|
1.7 |
5.1 |
15.89 |
18.00 |
20.00 |
21.40 |
22.90 |
1.8 |
9.0 |
48.35 |
55.20 |
59.60 |
63.90 |
68.30 |
|
1.8 |
5.4 |
17.81 |
20.80 |
22.40 |
24.00 |
25.70 |
2.0 |
10.0 |
59.69 |
68.20 |
73.60 |
78.90 |
84.30 |
|
2.0 |
6.0 |
21.99 |
25.60 |
27.70 |
29.70 |
31.70 |
2.2 |
11.0 |
72.22 |
82.50 |
89.00 |
95.50 |
102.00 |
|
2.2 |
6.6 |
26.61 |
31.00 |
33.50 |
35.90 |
38.40 |
2.4 |
12.0 |
85.95 |
98.20 |
105.00 |
113.00 |
121.00 |
|
2.4 |
7.2 |
31.67 |
37.00 |
39.90 |
42.80 |
45.70 |
2.5 |
12.5 |
93.27 |
106 |
114.00 |
123.00 |
131.00 |
|
2.6 |
7.8 |
37.16 |
43.40 |
46.80 |
50.20 |
53.60 |
2.6 |
13.0 |
100.88 |
115 |
124.00 |
133.00 |
142.00 |
|
2.8 |
8.4 |
43.10 |
50.30 |
54.30 |
58.20 |
62.20 |
2.8 |
14 |
116.99 |
133 |
144.00 |
154.00 |
165.00 |
|
3.0 |
9.0 |
49.48 |
57.80 |
62.30 |
66.90 |
71.40 |
3.0 |
15 |
134.30 |
153 |
165.00 |
177.00 |
189.00 |
