China Grade700-Grade1300 Steel Messenger Cable Galvanized Steel Wire Strand For Stay Wire As Per BS183 for sale

Grade700-Grade1300 Steel Messenger Cable Galvanized Steel Wire Strand For Stay Wire As Per BS183

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Brand: Litong Global

Product Description

Grade700-Grade1300 Galvanized Steel Wire Strand for stay wire as per BS183

Application:The galvanized steel wire strand is used for overhead ground lines or electrical power transmission lines. Stay or guy wire strands are produced for use with poles, towers, or any other form of guying

Standard:BS183

Construction	Approx. Strand Dia.	Min.Breaking Load of Strand
		Grade350	Grade 480	Grade700	Grade850	Grade1000	Grade1150	Grade1300	Approx.mass
	mm	KN	KN	KN	KN	KN	KN	KN	kg/1000m
7/1.25	3.8	3.01	4.1	6	_	8.55	9.88	11.15	67
7/1.4	4.2	3.75	5.17	7.54	9.16	10.75	12.35	14	84
7/1.6	4.8	4.9	6.75	9.85	11.95	14.1	16.2	18.3	110
7/1.8	5.4	6.23	8.55	12.45	_	17.8	20.5	23.2	140
7/2.0	6	7.7	10.55	15.4	_	22	25.3	38.6	170
7/2.36	7.1	10.7	14.7	21.4	_	30.6	35.2	39.8	240
7/2.65	8	13.5	18.5	27	_	38.6	44.4	50.2	300
7/3.0	9	17.3	23.75	34.65	_	49.5	56.9	64.3	392
7/3.15	9.5	19.1	26.2	38.2	_	54.55	62.75	70.9	430
7/3.25	9.8	20.3	27.85	40.65	_	58.05	66.8	75.5	460
7/3.65	11	25.6	35.15	51.25	_	73.25	84.2	95.2	570
7/4.0	12	30.9	42.2	61.6	_	88	101	114	690
7/4.25	12.8	34.75	47.68	69.5	_	99.3	114	129	780
7/4.75	14	43.4	59.45	86.8	_	124	142.7	161.3	970
19/1.6	8	13.37	18.34	26.75	_	38.2	43.93	49.66	300
19/2.0	10	20.9	28.65	41`.78	50.74	56.69	68.64	77.6	470
19/2.5	12.5	32.65	44.8	65.29	79.28	93.27	107.3	121.3	730
19/3.0	15	47	64.5	94	114.1	134.3	154.5	174.6	1050
19/3.55	17.8	65.8	90.27	131.6	159.9	188	216.3	244.5	1470
