China Low Carbon Galvanized Wire Rope , Zinc Coated Steel Wire For Greenhouses for sale

Low Carbon Galvanized Wire Rope , Zinc Coated Steel Wire For Greenhouses

Name: Low Carbon Galvanized Wire Rope , Zinc Coated Steel Wire For Greenhouses
Brand: Nanjing Suntay Steel Co.,Ltd

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Brand: Litong Global

Product Description

Galvanized Steel Wire Strand for Stay Wire as per BS 183

The galvanized steel wire strand is used for overhead ground lines or electrical power transmission lines. Stay or guy wire strands are produced for use with poles, towers, or any other form of guying

Specification

BS183:1972

Construction	Approx. Strand Dia.	Min.Breaking Load of Strand
		Grade350	Grade 480	Grade700	Grade850	Grade1000	Grade1150	Grade1300	Approx.mass
	mm	KN	KN	KN	KN	KN	KN	KN	kg/1000m
7/1.25	3.8	3.01	4.1	6	_	8.55	9.88	11.15	67
7/1.4	4.2	3.75	5.17	7.54	9.16	10.75	12.35	14	84
7/1.6	4.8	4.9	6.75	9.85	11.95	14.1	16.2	18.3	110
7/1.8	5.4	6.23	8.55	12.45	_	17.8	20.5	23.2	140
7/2.0	6	7.7	10.55	15.4	_	22	25.3	38.6	170
7/2.36	7.1	10.7	14.7	21.4	_	30.6	35.2	39.8	240
7/2.65	8	13.5	18.5	27	_	38.6	44.4	50.2	300
7/3.0	9	17.3	23.75	34.65	_	49.5	56.9	64.3	392
7/3.15	9.5	19.1	26.2	38.2	_	54.55	62.75	70.9	430
7/3.25	9.8	20.3	27.85	40.65	_	58.05	66.8	75.5	460
7/3.65	11	25.6	35.15	51.25	_	73.25	84.2	95.2	570
7/4.0	12	30.9	42.2	61.6	_	88	101	114	690
7/4.25	12.8	34.75	47.68	69.5	_	99.3	114	129	780
7/4.75	14	43.4	59.45	86.8	_	124	142.7	161.3	970
19/1.6	8	13.37	18.34	26.75	_	38.2	43.93	49.66	300
19/2.0	10	20.9	28.65	41`.78	50.74	56.69	68.64	77.6	470
19/2.5	12.5	32.65	44.8	65.29	79.28	93.27	107.3	121.3	730
19/3.0	15	47	64.5	94	114.1	134.3	154.5	174.6	1050
19/3.55	17.8	65.8	90.27	131.6	159.9	188	216.3	244.5	1470
