Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors
Price:
0.20-0.25
MOQ:
1000
Delivery Time:
10-15 days
Brand:
IKP
Product Description
Basic Info.
Model NO.
IKP-LF-UU Series
Working Frequency
High Frequency
Structure of Winding
Multilayer Coil
Nature of Operation
Choke Coil
Structure of Magnetizer
Ferrite Coil
Range of Application
Choke
Packaging Form
Power Coils
Brand
OEM/ODM
Inductor Value
Variable Inductor
Transport Package
Carton
Specification
UU Type
Trademark
IKP-ELEC
Origin
Hefei, China
HS Code
85043190
Production Capacity
50000 Pieces/Day
Product Description
Features:
1. Small size
2. Easy to round
3. Low price
4. High reliability
5. Meeting UL, VDE, CSA requirements
6. UL approved Class 130°C insulation system is available
7. Windings balanced within 1%
8. Customized specifications are welcome
9. Small, medium and high quantity is available
Application:
1. Switching power supply
2. Lighting application
3. Machinery
4. Telecommunication equipment
5. Medical application equipment
6. Home appliance
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
![Uu9.8/Uu10.5/Uu15.7/Uu16 Type EMI Common Mode Choke Inductors]()
1. Small size
2. Easy to round
3. Low price
4. High reliability
5. Meeting UL, VDE, CSA requirements
6. UL approved Class 130°C insulation system is available
7. Windings balanced within 1%
8. Customized specifications are welcome
9. Small, medium and high quantity is available
Application:
1. Switching power supply
2. Lighting application
3. Machinery
4. Telecommunication equipment
5. Medical application equipment
6. Home appliance
| Model | Mounting style | Length | Width | Height | One side pins and pin distance | The other side pins and pin distance | Row distance | Pin Diameter | ||
| UU9.8-01 | Vertical | 17.0 | 12.0 | 17.0 | 2 | 7.0 | 2 | 7.0 | 8.0 | Φ0.6 |
| UU9.8-02 | Vertical | 17.0 | 16.0 | 13.0 | 2 | 7.0 | 2 | 7.0 | 8.0 | Φ0.6 |
| UU10.5-01 | Vertical | 19.0 | 17.5 | 22.0 | 2 | 10.0 | 2 | 10.0 | 13.0 | Φ0.7 |
| UU10.5-02 | Vertical | 19.0 | 19.0 | 17.0 | 2 | 10.0 | 2 | 10.0 | 13.0 | Φ0.7 |
| UU15.7-01 | Vertical | 23.0 | 19.0 | 26.5 | 2 | 10.0 | 2 | 10.0 | 13.0 | Φ0.7 |
| UU15.7-02 | Vertical | 23.0 | 25.0 | 23.0 | 2 | 10.0 | 2 | 10.0 | 13.0 | Φ0.7 |
| UU16-01 | Vertical | 23.0 | 19.0 | 26.5 | 2 | 10.0 | 2 | 10.0 | 13.0 | Φ0.7 |
| UU16-02 | Vertical | 23.0 | 25.0 | 23.0 | 2 | 10.0 | 2 | 10.0 | 13.0 | Φ0.7 |
