Uu/Ut Common Mode Choke Inductors
Price:
0.165-0.19
MOQ:
1000
Delivery Time:
10-15 days
Brand:
IKP
Product Description
Basic Info.
Model NO.
IKP-UT20-9
Working Frequency
High Frequency
Structure of Winding
Multilayer Coil
Nature of Operation
Choke Coil
Structure of Magnetizer
Ferrite Coil
Range of Application
Choke
Packaging Form
Power Coils
Brand
OEM/ODM
Inductor Value
Variable Inductor
Bobbin
Ut20
Transport Package
Carton/Pallet
Specification
Rohs, ISO9001
Trademark
IKP-ELEC
Origin
Hefei, Anhui
HS Code
85045000
Production Capacity
50, 000 PCS/Day
Product Description
Features:
1. Operating Frequency: 50~200KHz
2. Low-cost, all models mainly used in less demanding fields on the electromagnetic shielding power field.
3. Power frequency because of work, safety regulations and other requirements of the different temperature level will change.
Specifications (Unit: mm):
| PART NO. | PINS | Dimensions in mm (inches) | |||||
| A | B | C+/-0.5 | D+/-0.5 | E+/-0.5 | F | ||
| IKP-UT-20-01 | 4 | 23.5 | 17.5 | 10 | 4 | 13 | 22.5 |
Note: The above are common skeleton styles; we accept customer requirements ODM or OEM. Welcome your design drawings or samples.
Electrical performance:
1. Operating frequency: 20kHz-500KHz
2. Output power: 30 to 80 W
3. Operating temperature:-40 ºCto +125 ºC
4. Storage temperature:-25 ºCto +85 ºC
Applications:
Household appliances, switching power supplies, communications equipments, medical equipments, production equipments, CCTV, computers, lighting equipments.
Kindly Reminder:
1. About the SAMPLES. Please provide specific specifications or sample material, we will evaluate your products, design and produce samples.
2. About PRICE. Transformers are custom products, due to the different materials and design, even if the same model, the price is not the same. The price also depends on the complexity of the parameters and the amount of orders.
3. About SHIPPING. Samples in 3-5 days; mass production in 7-15 days.
5. Packaging, logistics, according to the specific requirements of the purchase and sale contracts.
6. Contact us now for more details.
