16 ports 10/100/1000M Gigabit Ethernet Switch with 2 SFP ports
16 ports 10/100/1000M Gigabit Ethernet Switch with 2 SFP ports
Model: LNK-216G-SFP Series
Overview
LNK-216G-SFP Series Ethernet Fiber Switch has 16 10/100/1000Mbps Ethernet ports and 2 SFP ports. All ports support wire-speed forwarding and Auto MDI/MDIX function. Users can choose different SFP modules in need. No configuration is required; it will instantly operate as soon as you power it up. This series is designed for 19 inches of rack chassis.
Features
- 16* 10/100/1000M Ethernet ports ,2*1000M SFP ports
- Support 10/100/1000M rate with auto-negotiation function,support MDI/MDIX and half/full-duplex with auto-negotiation function
- Each port has the complete LED Indicator light
- All ports support wire-speed forwarding
- Support IEEE802.1d Spanning Tree
- Support high performance QoS function on each port,support multicast
- Support IEEE 802.3x flow control and back pressure control
- Support 10K bytes Jumbo packet
- Support IEEE802.1Q protocol of 4K VLAN table
- Support 4KV port lightning protection
- Standard IU chassis design,easy installation
- Require no configuration and will instantly operate as soon as you power it up
- Fanless design,no noise, lower the power consumption and longtime operation
Technical Indexes
|
Standards |
IEEE802.3 10Base-T IEEE802.3u100Base-TX/FX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX/LX IEEE802.3x Flow control IEEE802.1p QoS IEEE802.1d Spanning Tree IEEE802.1q VLAN |
| Certifications | CCC, CE, FCC, RoHS |
|
Ethernet Port |
Connector: RJ45 Data Rate: 10/100/1000M adaptive Distance: 100m UTP Type: UTP-5E or higher level |
|
Fiber Port |
Connector: SFP slot Data Rate: 1.25Gbps Optical Wavelength: 850nm/1310nm/1490nm/1550nm Fiber Type: single mode 9/125μm, multi-mode 50/125μm, 62.5/125μm Distance: 550m～100km |
|
Performance |
Processing Type: Store and Forward Transmission mode: half/full-duplex with auto-negotiation function MAC Table Size: 8K Buffer Space: 4.1Mbit Maximum Packet Length:10K bytes Back bandwidth: 36G Time Delay: ＜20μs |
|
Power |
Power type: external power supply Input Voltage: AC100V～240V 50/60Hz Connector: AC Socket Power Consumption: 3W～10W |
|
Environment |
Storage Temperature:-40～70℃ Operating Temperature: -10～55℃ Relative Humidity: 5-90% ( no condensation) |
| Warranty | 2-year |
| Physical Characteristics |
Dimension: 440×170×45mm Weight: 2.0kg Color: Metal, Blue |
Ordering Information
| Model | Description |
| LNK-216G-SFP | 16-port 10/100/1000M Gigabit Switch with 2 SFP slots, not including SFP modules, standalone |
