1000Mbps RJ45 FX1 Fiber Optic Switch 2 Port 10/100/1000Base-T Aluminum Case
Price:
220USD(1-5) 200USD(＜100) 195USD(>100)
MOQ:
1 pcs
Delivery Time:
7 working days
Brand:
E-link
Product Description
Fiber Optic Switch 2-port 10/100/1000Base-T + 8-port 1000BASE-X SFP Ethernet Switch
Advantages
- 2 10/100/1000Base-TX + 8 1000Base-X SFP
- 10/100/1000Mbps RJ45 Port
- Supports 802.3x Flow control
- 9K Bytes Jumbo Frame
- Redundant Power Inputs
| Technical Indexes | |
| Forward & Filtering Rate: | 14,880pps (10Mbps) |
| 148,800pps (100Mbps) | |
| 1,488,000pps (1000Mbps) | |
| Packet Buffer Memory: | 2.75M bits |
| Max Packet Length: | 9K Bytes Jumbo Frame |
| Address Table Size: | 8K MAC Addresses |
| Interface | |
| Ethernet Port: | 2 x RJ45 |
| Optical Port: | 8 x 1000Base-X SFP |
| Environmental | |
| Operating Temperature: | -40°C to 80°C (-40°F to 176°F) |
| Storage Temperature: | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity: | 5% to 95% non-condensing |
| MTBF | > 200,000 hrs |
| Electrical and Mechanical | |
| Input Power: | 12~57VDC , Redundant Power (6-pin Terminal Block) |
| Power Consumption: | 12W Max. |
| Protection: | |
| Power Input Overload: | Automatic Resettable |
| Dimensions (WxDxH): | 149 x 110 x 50 mm |
| Weight: | 0.5Kg |
| Casing: | Aluminum Case |
| Mounting Options: | DIN-Rail / Wall-mount |
Overview
LNK-IMC802G-SFP Series is a unmanaged 8 ports 1000Base-X SFP + 2 ports 10/100/1000Base-T Optical Ethernet Switch. The Switch provides SFP slot to support the use of SFP (Small Form-factor Pluggable) transceiver module. User can choose different types of SFPs (1.25g only). The Switch supports 1 or 2 core Single-mode or Multi-mode fiber.
