Medium Intensity Solar Aviation Obstruction Light FAA L864 Marking TV Towers Safety
Medium Intensity Solar Aviation Obstruction Light FAA L864 Marking TV Towers Safety
This Medium-intensity Type B Aviation Obstruction Light flashing red color, designed for marking top of obstacle which height is between 45 to 105 meters.
Compliance
** ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 Medium Intensity Type B Obstruction Light
** FAA L-864
Electrical
* CREE ultra high intensity LED as light source saving power consumption and maintenance than incandescent light or halogen lamp
* Power supply available in DC(12-48VDC) or AC(110-240VAC)
Physical
Unique design and UV protected polycarbonate lens for converging light
UV protection Powder coated bright yellow color base make better visibility
Base material is die casting aluminum which has strong corrosion resistance, Shock and Vibrations protection
Special valve installed beside the base to make sure the air could go through but water is avoid, so that the whole light temperature won’t be high.
System design
♦ Built-in photocell for day/night operation(dusk to dawn operation)
♦ Surge and lightning protection
♦ Main-standby mode
Optional
► Alarm contact for remote monitoring
► Infrared LED for pilot using NVG
► GSM cellphone monitoring
► RS485/232 communication part for monitoring
► User adjustable flashing rate(20, 30, 40, 60 flashes/minute)
► GPS synchronization
Application
AH-MI-B2 medium-intensity aircraft warning light is used on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the obstacle height is 45-105meter, and most time work with low intensity lights installed on the lower place.
More detailed parameter:
| Body Material | Polycarbonate (High borosilicate glass as optional) |
| Base Material | Powder-coated Die-casting aluminum |
| Flash Characteristics | 20-60 flashes per minute |
| Operation Mode | Dusk-to-dawn Automatically as standard.24hours operation as option |
| Operating Voltage | DC(12-48VDC) or AC(110-240VAC) |
| Power(W) | 11 |
| Product Life Expectancy | 5 years Plus |
| Humidity | 0%-100% |
| Wind Speed | 80m/s |
| Waterproof | IP66 |
| ICAO | Annex 14 Volume 1,'Aerodrome Design and Operations’ Sixth edition 2013, table 6.3 Medium-intensity Type B Red Obstacle Light |
| FAA | L-864 |
