High Chimney Led Aircraft Warning Lights ICAO Aviation Obstruction Lamp FAA L865 20000cd
High Chimney Led Aircraft Warning Lights ICAO Aviation Obstruction Lamp FAA L865 20000cd
This Medium-intensity Type A&B Aviation Obstruction Light flashing white color at daytime and red color at night. It’s designed for marking top of obstacle which height is between 45 to 150 meters.Ultra high intensity CREE LED is used for the light source ensure light’s long life experience and good performance.
Compliance
** ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 Medium Intensity Type A Obstruction Light, Medium Intensity Type B Obstruction Light
** FAA L-865 & FAA L-864
Electrical
* CREE high intensity LED as light source saving power consumption and maintenance than incandescent light or halogen lamp
* Power supply available in DC(12-48VDC) or AC(110-240VAC)
Physical
UV protected polycarbonate lens for converging light
UV protection Powder coated bright yellow color base make better visibility
Base material is die casting aluminum which has strong corrosion resistance, Shock and Vibrations protection
Special valve installed beside the base to make sure the air could go through but water is avoid, so that the whole light temperature won’t be high.
System design
♦ Built-in photocell ensure light emitting red color at night and white color at daytime automatically
♦ Surge and lightning protection
Optional
► Alarm contact for remote monitoring
► Infrared LED for pilot using NVG
► GSM cellphone monitoring
► RS485 communication part for monitoring
► GPS synchronization
Application
AH-MI-AB LED medium-intensity aviation obstruction light is used on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc when the obstacle height is 45-150meter, and most time work with low intensity lights installed on the lower place.
More detailed parameter:
| Emitting Colors | White (Daytime); Red (Night) |
| Intensity(cd) | 20000cd±25%(Daytime), 2000cd±25%(Night) |
| Flash Characteristics | 40FPM(flashes per minute) |
| Body Material | Polycarbonate (High borosilicate glass as optional) |
| Base Material | Die-casting aluminum |
| Dimension(mm) | 236*236*230 |
| Operating Voltage | DC(12-48VDC) or AC(110-240VAC) |
| Power(W) | 15(Daytime), 10(Night) |
| Product Life Expectancy | 5 years Plus |
| Humidity | 0%-100% |
| Wind Speed | 80m/s |
| Waterproof | IP66 |
| ICAO | Annex 14 Volume 1,'Aerodrome Design and Operations’ Sixth edition 2016, table 6.3 Medium-intensity Type A White Obstacle Light Medium-intensity Type B Red Obstacle Light |
| FAA | L-864,L-865 |
