This heliport beacon light should be provided at a heliport where long-range visual guidance is considered necessary and is not provided by other visual means; or identification of the heliport is difficult due to surrounding lights. The heliport beacon shall be located on or adjacent to the heliport preferably at an elevated position and so that it does not dazzle a pilot at short range.
AH-HP-B1 flashes white color 4 times/0.8second and stop for 1.2s, then start new circle for 2seconds(0.8s+1.2s ). Fully meet your needs.

Compliance

** ICAO Annex 14 Volume ǁ Heliports 5.3.2
** FAA AC 150/5390-2B Heliport Design Guide
**  CAP 437

Electrical
 LED as light source saving power consumption and maintenance, 95% less power than equivalent incandescent light
 Power supply available in DC(12-48VDC) or AC(110-240VAC)

Physical
* Clear polycarbonate lens for converging light and also provides corrosion resistance and UV protection.
* UV protection Powder coated bright yellow color base make better visibility
* Base material is die casting aluminum which has strong corrosion resistance, Shock and Vibrations protection

Optional
► Controller for power supplying and turn ON/OFF light
► VHF pilot to ground remote control

Application
     Helipad/Heliport/Helideck

 More product parameter:

Online communication:

Delivery:

We will try our best to help every customer also provide professional technical support. If you have any question,feel free to contact me. We have more than 8 years manufacturing experience for clients from whole world
