SMD5050 Safety LED Flexible Strip Lights High Voltage Temp Regulation Protection
Waterproof 24V LED Flexible Strip Lighting Explosion Proof For Underground Mine
Product Description
Our plug and play system
Conventional lighting requires separate power and a wired connection to every lamp, needing the expertise of electricians. This becomes labour-intensive and costly when running many meters of lighting. The LED Strip Lighting plugs into an existing power source using a power supply which then connects to one end of the LED strip.
Maintenance-free. Easy to repair.
Damage to lighting through routine underground activities happens. When a conventional lamp is damaged, it results in loss of illumination over many meters – making the affected area a safety hazard until repaired by a qualified electrician. Should a section of the strip light be damaged, only this section loses light. The remaining portion of the strip continues to provide illumination – allowing for a safer environment. Additionally, damaged sections can be replaced in 8" strips – making it a quick and cost-effective fix.
• Intelligent temperature management, sensors monitor LED temperature and if safe parameters are exceeded the affected LED’s are automatically dimmed until safe temperatures are restored.
• Intelligent voltage surge management, restorable resistors limit overcurrent and overvoltage situations.
• AC to DC convertors, miniature voltage convertors.
• Short circuit protection, in the case of short circuit the power is isolated until the circuit is normalized.
Dimension: 10000mm(length) *20mm(width) *10mm(height)
Main Parameter of GL-XLM-GS01 led strip lights waterproof
TECHNICAL PARAMETERS:
| Part Number | GL-XLM-GH02 |
| LED Chip | Epistar |
| LED configuration | 60 LED's spaced evenly over a metre length |
| Range fed from both sides | 20 metres |
| Recommended fixing height | 5 - 6 Metres |
| IP Rating | 68 |
| Power Consumption per LED | 0.25 Watts |
| Power Consumption per Metre | 15 Watts |
| Colour Rendering Index CRI | > 80 |
| Colour temperature | 6500 Kelvin |
| Luminous Efficacy | 80 Lumens / Watt |
| Voltage on lighting VDC | 24 VDC |
| Supply voltage for power controllers VAC | 85 - 265 VAC |
| Light maintenance | 15%-20% Drop over 4 years |
| Lifespan | 5 Years + |
| Warranty Lighting | 3 Years |
| Outer covering | Food grade silicone |
| Dimensions | 10000mm(length) *13.5mm(width) *6mm(height) |
| Tensile strength | +-50KG |
| Operating temperature | -40℃ to 120℃ |
| Protection | Short Circuit Over Voltage Over temperature Over Current |
GREEN LIGHTING TECHNOLOGY INTRODUCTION:
GREEN LIGHTING focus on LED Industrial products, Such as LED miner cap lamp, LED Strip light, LED explosion-proof troch, charging devices for more than 12 years.
The main service we do is CUSTOMIZED, according to customer's request to design new items to meet client's market
positioning and use condition.
Strong ID Team, Rich Experience Electronic Circuit Team, Professional MD Team, Outstanding Optical Design Team to design the product what clients needs,cooperating with many clients with customized service around the world for different products,we manufacture best quality products by having a company culture of continuous improvement in the quality of our end products and services to our customers.
Quality is the main focus in company because we valve our customers. We strive to provide our customers with products and services which meet and even exceed their expectation.Selective and performance monitoring of supplier against set criteria.
Measurable quality objectives which reflect our business aim.Regular audit of internal processes.
Warranty, GREEN LIGHTING provides one year product warranty.
GREEN LIGHTING assures the quality and also gives maintenance free during one year tenure.
We also provides maintenance of the cap lamps after one year tenure for having best relationship with customers.
