1mm 1.2mm 304 Stainless Steel Crimped Wire Mesh For Baking Tray

Price Negotiable

Price: USD5-25 per square meter

MOQ: 5 square meters

Delivery Time: 5-8 work days

Brand: COMESH

Product Description

1mm 1.2mm 304 Stainless Steel Woven Crimped Wire Mesh For Baking Tray

1. Description :

Material: 201, 304, 316, 316L stainless steel wire; galvanized wire; iron wire

Mesh/inch: 1-24 mesh/inch

Width: 1-5m

Wire Gauge SWG	Wire Diameter mm	Mesh/Inch	Aperture mm	Weight kg/m2
14	2.0	21	1	4.2
8	4.05	18	1	15
25	0.50	20	0.61	2.6
23	0.61	18	0.8	3.4
24	0.55	16	0.1	2.5
24	0.55	14	0.12	4
22	0.71	12	0.14	2.94
19	1	2.3	0.18	1.45
6	4.8	1.2	2	20
6	4.8	1	2	20
6	4.8	0.7	3	14
14	2.0	5.08	0.3	12
14	2.0	2.1	1	2.5
14	2.0	3.6	1.5	1.9

2. Application :

Stainless steel crimped wire mesh: Mainly used in food, mining, chemical, pharmaceutical, petroleum, metallurgy, machinery, protection, construction, handicrafts and other industries.

Galvanized wire crimped wire mesh: Isolation and protection of civil and aquaculture industries

3. Features :

1) Heat resistant. The highest operating temperature is under 800 degree.
2) Corrosion resistance
3) High strength
4) Durable.
5) Smooth and clean
6) High finish,no need to surface treatment
