0.012 - 4.5mm Round Ultra Fine Magnet Wire , 24 Awg Copper Enameled Wire For Automation
Enamelled Copper WIre , 0.8-4.5mm UL certificated round magnet wire , superfine size available
The enamelled cooper wire Ruiyuan provide combines the magnet wire insulation characteristics of polyurethane with the advantages of a polyamide (nylon) topcoat. With the nylon, the wire is still readily solderable, yet the solvent resistance and thermal stability of the insulation is excellent. In addition, the nylon improves windability and tolerates more severe winding operations. Ruiyuan is an excellent choice for automatic winding machines.
Features and benefits:
1. SIze range:0.8-4.5mm
2. Insulation: Polyester w/ Polyamideimide Overcoat
3. NEMA Description: MW-35-C
4. Build: Heavy Min-Nom
5. Temperature Rating: 130-220°C (392°F)
Certificates:
ISO 9001-2000, ISO TS 16949, ISO 14001-2004,
UL Approved, RoHS Directive Met
Executive standards
IEC, JIS and NEMA.
Applications of enamelled copper wire:
1. Power Electronics
2. Drive engineering
3. Medical technology
4. Railway Engineering
5. Automation
Thermal ratings:
| ELANTAS | Temperature Class Degrees C |
| Polyvinyl Formal | Class 105 |
| Polyurethane/Polyamide (Nylon) | Class 155 |
| Polyurethane | Class 155 |
| Polyurethane/Polyamide (Nylon) | Class 180 |
| Polyurethane | Class 180 |
| Solderable Polyester | Class 180 |
| Solderable Polyester/Polyamide (Nylon) | Class 180 |
| Modified Polyester/Polyamide (Nylon) | Class 180 |
| Modified Polyester/Polyamideimide | Class 200 |
| Modified Polyester | Class 200 |
| Modified Polyester/Polyamideimide | Class 200 |
| Modified Polyester/Polyamideimide | Class 220 |
| Polyimide | Class 240 |
| Polyvinyl Butyral Self Bonding over Polyurethane / Nylon |
Class 130 |
| Modified Polyester/Polyamideimide/Bondcoat | Class 180 |
