50g 3UEW 0.012mm Enameled Ultra Fine Copper Wire Super Thin Magnet Copper Wire For Touch Screen
50g 3UEW 0.012MM ENAMELED ULTRA FINE COPPER WIRE SUPER THIN MAGNET COPPER WIRE FOR TOUCH SCREEN
We are the producer of fine and ultrafine enamelled copper wire (winding wire). It is produced and delivered corresponding to the industry standards IEC 60317, NEMA MW1000, JIS C3202 or to customer specific requirements. Besides enamelled copper wire Elektrisola produces enamelled wire made from many other metals as well as selfbonding wire and litz wire.We also can produce the wire according to your request, because sometimes the standard is too wide.Comparing with other competitor, we are the only manufacture who can produce the 0.012mm ultra fine enamled copper wire for mass production, and we also can provide in small quanity such as 50g.
|
|
Characteristics |
Technical requests |
Test Results |
Conclusion |
||||||||
|
Sample 1 |
|
|
||||||||||
|
1 |
Surface |
Good |
OK |
|
|
OK |
||||||
|
2 |
Bare Wire Diameter |
0.012± |
0.0005 |
0.0120 |
|
|
OK |
|||||
|
0.0005 |
||||||||||||
|
3 |
Coating Thickness |
≥0.002mm |
0.003 |
|
|
OK |
||||||
|
4 |
Overall Diameter |
≤0.016mm |
0.015 |
|
|
OK |
||||||
|
5 |
Conductor Resistance |
≤165.99Ω/m |
155.18 |
|
|
OK |
||||||
|
6 |
Elongation |
≥5% |
7 |
|
|
OK |
||||||
|
7 |
Breakdown Voltage |
≥110 V |
382 |
|
|
OK |
||||||
|
8 |
Pinhole Test |
≤12holes/5m |
0 |
|
|
OK |
||||||
|
|
|
|
|
|
|
|
||||||
|
Remark: |
||||||||||||
|
|
Test Items |
Technical Requests |
Results |
Conclusion: Approved |
||||||||
|
1 |
Adhesive |
Coating layer is good |
OK |
|||||||||
|
2 |
Cut-through |
200℃ 2mins no breakdown |
OK |
|||||||||
|
3 |
Heat Shock |
175±5℃/30min no crack |
OK |
|
|
|||||||
|
4 |
Solder Ability |
390± 5℃ 2 Sec Smooth |
OK |
|
|
|||||||
|
|
|
|
|
|||||||||
