EIAIW CLASS 200 Enamel Insulated Wire / Magnet Copper Wire IEC NEMA Standard
EIAIW CLASS 200ENAMELED INSULATED WIRE MAGNET COPPER WIRE IEC NEMA STANDARD
Amide - Imide overcoated Polyester - Imide Enameled copper wire is a dual film s insulation composed of Polyester - Imide or modified polyester with polyamideimide(AI),It's also called EIAIW enameled copper wire.It is designed for continuous operation at 200C, provides superior abrasion resistance, solvent resistance and moisture, refrigerants resistance.
FEATURES
-
Excellent wet/dry dielectric characteristics and moisture resistance compared favorably with PEW+NY
-
Excellent flexibility, film adhesion and cut throught reisstance
-
Superior "Q" characteristics at high frequencies.
-
Excellent resistant to a variety of solvents including most varnishes and hardener catalysts.
APPLICATION
Motors, dry transformers, heavy dutu hand tool motor,s encapsulated coils
| Conductor | Minimum film thickness | Maximum overall thickness | Break Down Voltage | Failing load in resistance-to- abrasion test N (gf) |
Maximun conductor resistance per unit length | Minimum elongation | ||
| Diameter | Tolerance | Average value | Lowest value | W / km (20oC) | ||||
| mm. | mm. | mm. | mm. | V | (min.) | (min.) | % | |
| 0.1 | 0.008 | 0.009 | 0.14 | 2000 | - | - | 2647 | 15 |
| 0.11 | 0.15 | 2153 | ||||||
| 0.12 | 0.01 | 0.162 | 2200 | 1786 | ||||
| 0.13 | 0.172 | 1505 | ||||||
| 0.14 | 0.182 | 1286 | ||||||
| 0.15 | 0.192 | 1111 | ||||||
| 0.16 | 0.011 | 0.204 | 969.5 | |||||
| 0.17 | 0.214 | 853.5 | ||||||
| 0.18 | 0.012 | 0.226 | 2400 | 757.2 | ||||
| 0.19 | 0.236 | 676.2 | ||||||
| 0.2 | 0.246 | 607.6 | ||||||
| 0.21 | 0.256 | 549 | ||||||
| 0.22 | 0.266 | 498.4 | ||||||
| 0.23 | 0.013 | 0.278 | 454.5 | |||||
| 0.24 | 0.288 | 416.2 | ||||||
| 0.25 | 0.298 | 382.5 | ||||||
| 0.26 | 0.01 | 0.31 | 3.5{357} | 3.0{306} | 358.4 | |||
| 0.27 | 0.32 | 331.4 | ||||||
| 0.28 | 0.33 | 3.6{367} | 307.3 | |||||
| 0.29 | 0.34 | 3.1{316} | 285.7 | 20 | ||||
| 0.3 | 0.014 | 0.352 | 2800 | 3.9{398} | 3.3{337} | 262.9 | ||
| 0.32 | 0.372 | 230 | ||||||
| 0.35 | 0.402 | 4.0{408} | 3.4{347} | 191.2 | ||||
| 0.37 | 0.424 | 170.6 | ||||||
| 0.4 | 0.015 | 0.456 | 4.4{449} | 3.7{337} | 145.3 | |||
| 0.45 | 0.016 | 0.508 | 4.7{479} | 4.0{408} | 114.2 | |||
| 0.5 | 0.017 | 0.56 | 3050 | 5.1{520} | 4.4{449} | 91.43 | ||
| 0.55 | 0.02 | 0.62 | 78.15 | |||||
| 0.6 | 0.672 | 65.26 | ||||||
| 5.2{530} | 4.5{459} | |||||||
| 0.65 | 0.018 | 0.724 | 5.6{571} | 4.8{490} | 55.31 | |||
| 0.7 | 0.019 | 0.776 | 6.0{612} | 5.1{520} | 47.47 | |||
| 0.75 | 0.02 | 0.83 | 3400 | 6.4{653} | 5.4{551} | 41.19 | ||
| 0.8 | 0.021 | 0.882 | 6.7{683} | 5.7{581} | 36.08 | 25 | ||
| 0.85 | 0.022 | 0.934 | 7.1{724} | 6.0{612} | 31.87 | |||
| 0.9 | 0.023 | 0.986 | 7.5{765} | 6.4{653} | 28.35 | |||
| 0.95 | 0.024 | 1.038 | 7.9{806} | 6.7{683} | 25.38 | |||
| 1 | 0.03 | 0.025 | 1.102 | 8.3{847} | 7.0{714} | 23.33 | ||
| 1.1 | 1.204 | 8.7{887} | 19.17 | |||||
| 0.026 | 4150 | 7.4{755} | ||||||
| 1.2 | 1.304 | 8.8{898} | 16.04 | |||||
| 1.3 | 0.027 | 1.408 | 9.2{938} | 7.8{796} | 13.61 | |||
| 1.4 | 1.508 | 9.3{949} | 7.9{806} | 11.7 | ||||
| 1.5 | 0.028 | 1.612 | 9.8 {1000} | 8.2{836} | 10.16 | |||
| 1.6 | 1.712 | 8.3{847} | 8.906 | |||||
| 1.7 | 0.029 | 1.814 | 4350 | 10{ 1020} | 8.7{887} | 7.871 | ||
| 1.8 | 1.914 | 7.007 | ||||||
| 1.9 | 0.03 | 2.018 | 11{ 1120} | 9.1{928} | 6.278 | |||
| 2 | 2.118 | 9.2{938} | 5.656 | 30 | ||||
| 2.1 | 0.031 | 2.22 | 9.5{968} | 5.123 | ||||
| 2.2 | 0.032 | 2.322 | 12{ 1220} | 9.8 | 4.662 | |||
| { 1000} | ||||||||
| 2.3 | 2.422 | 9.9{ 1010} | 4.26 | |||||
