UL Certificated 2UEW 0.02mm Self Bonding Copper Wire For Voice Coils Hot Air

Price Negotiable

Price: Negotiation

MOQ: 20Kilogram/Kilograms

Delivery Time: 2-15 days

Brand: Ruiyuan

Product Description

UL Certificated 2UEW 0.02mm Self Bonding Enameled Copper Wire For Voice Coils Hot Air

We are one of the pioneers in producing micro thin enameled wires below 0.03mm in China. Our R & D team has 20 years of market experience.We have achieved the goal of "zero pinholes after stretching" for ten years.

We surpass them in terms of "service, quick response"; 30% lower "price" is our advantage.

Size range: 0.011mm-1.2mm

Characteristics	Technical requests	Test Results
Characteristics	Technical requests	Sample 1	Sample 2
Surface	Good	OK	OK
Bare Wire Diameter	0.020±0.001	0.02	0.02
Overall Diameter	0.022-0.024	0.023	0.023
Conductor Resistance	≤60.810Ω/m	56.812	56.403
Elongation	≥8%	10%	10%
Breakdown Voltage	≥130V	212	247
Pinhole Test	≤ 8 holes/5m	1	0
Test Items	Technical Requests		Results
Adhesive	Coating layer is good		OK
Cut-through	200℃ 2mins no breakdown		OK
Heat Shock	180±5℃/30min no crack		OK
Solder Ability	390± 5℃ 2 Sec Smooth		OK
Solvent Resistance	No blister, no expansion, no shed		OK
