Conductive Carbon Coated Aluminum Foil 0.012 - 0.040 Mm Basis Material

Price Negotiable

Price: usd 26 per kg

MOQ: 100kg

Delivery Time: 20-30 days

Brand: JIMA

Product Description

Conductive carbon coating aluminum aluminium al foil for Cathode electrode Cathode Substrate current collector positive materials.

Product Type:CAW2.

Quickly Details

Double side Coated thickness:min 500nm,A: 4~6um B: 2~3um.
Package:Wooden box.
Surface Color:Black.

Double side coating	A: 4~6um B: 2~3um
Purity	> 99.9%
Density	1.0 -2.5 g/m2
Treatment	Coated
Packing detail	Wooden box
Aluminum foil thickness	12-40um
Color	Black

Features:

Reduce internal resistance of the cell.
Decrease polarization.
Improve the rate capability.

Application:

(LFP.LMO.NCM.NCA.LNM.LTO):for electric vehicles

(LFP.LMO.NCM.NCA.LNM.LTO):energy storage

3C (LCO.NCM):Lithium-ion batteries for 3C productions

Super capacitor

Lithium-ion super capacitor

Physical and chemical properties (MTC of CAW2 ).

Planar density (Both side)	1.0g/m2 1.0±0.2mg/cm2	1.5g/m2 1.5±0.3mg/cm2	2.0g/m2 2.0±0.3mg/cm2	2.5g/m2 2.5±0.3mg/cm2
Covering rate	min.80%	min.90%	Min.100%	min.100
Conductivity	~30S/cm	~30S/cm	~30S/cm	~30S/cm
Peeling Strength	2.0N	2.0 N	2.5N	2.5N
Corrosion resistance	No exfoliation	No exfoliation	No exfoliation	No exfoliation

Important Matters:

Use the product under the temperature of 20-25℃ and humidity of ≤20%RH

The coating layer is highly Hydrophilic, handle it under personal protection.

Avoid using the product under dust, The dust purification should be over 0.1M.

Avoid any collisions against hard materials. Handle the product gently.

Usage and storage note:

The product can be stored under vacuum package for one year at ambient temperature and moisture without direct sun. Once the vacuum package is opened, the product can be kept under vacuum cabinet for at most one month.

Package:wooden carton.

FAQ:

Q1: What's your minimum order quantity?

A: The MOQ is 150 kg.

Q2. Length per roll?

A: 500-10000meter

Q3. How to save after the box opened?

A: The product can be stored under vacuum package for one year at ambient temperature and moisture without direct sun. Once the vacuum package is opened, the product can be kept under vacuum cabinet for at most one month.
