RoHS Certificated FPC Copper Foil Sheet,6um Electrodeposited Copper Sheet Metal
Price:
Negotiation
MOQ:
100kg
Delivery Time:
5- 25days
Brand:
JIMA
Product Description
Ultra thickness 6um electrodeposited copper foil for Lithium-ion Battery
Quickly details
| Ultra ThicknesS | 6micron,6um,0.006mm |
| Width Range | within1380 mm |
| Length | 500M-5000 M |
| Features |
Excellent uniformity and infiltration. double shiny side ,superior rupture endurance. Surface:No indentation,No scratches,No wrinkles,No tear and other defect. thickness standard tolerance:within +/-0.00054mm Roughness:0.025um Width standard tolerance:+/-1.5mm Ultra thickness |
| Packing | standard export sea wooden box |
| Cu Content (%) | Above 99.8% |
| ID of Roll | 76mm,152mm,can custom |
| Roll Weight |
100kgs~350kgs |
|
Specification
Thickness: 6µm~20µm
| Test Item | Unit | Thickness | ||||||
| 6μm | 7μm | 8μm | 9/10μm | 12μm | 15μm | 20μm | ||
| Cu Content | % | ≥99.9 | ||||||
| Area Weight | mg/10cm2 | 54±1 | 63±1.25 | 72±1.5 | 89±1.8 | 107±2.2 | 133±2.8 | 178±3.6 |
| Tensile Strength(25℃) | Kg/mm2 | 28~35 | ||||||
| Elongation(25℃) | % | 5~10 | 5~15 | 10~20 | ||||
| Roughness(S-side) | μm(Ra) | 0.1~0.4 | ||||||
| Roughness(M-side) | μm(Rz) | 0.8~2.0 | 0.6~2.0 | |||||
| Width Tolerance | Mm | -0/+2 | ||||||
| Length Tolerance | m | -0/+10 | ||||||
| Pinhole | pcs | None | ||||||
| Change of Color | 130℃/10min 150℃/10min | None | ||||||
| Wave or Wrinkle | / | Width≤40mm one allow | width≤30mm one allow | |||||
| Appearance | / | No drape, scratch, pollution, oxidation, discoloration and so on that effect using | ||||||
| Winding method | / | The winding when facing up S side, when the winding tension in the stable,no loose roll phenomenon | ||||||
Details Packing: standard export sea wooden box package
FAQ:
Q1: Can you supply the sample?
A: We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.
Q2. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q3. what is your standard width?
A: 1290mm,max width is 1380mm,,we accept customization for the width. we can cut it into any size that you demand after pass discussing
Q4. Can you provide COA?
A:Yes , we can.
A:Yes , we can.
Q5. Can we come to China visit factory ?
A5:Yes ,you can .
A5:Yes ,you can .
Q6. Can you cut into small size?
A:Yes, we can.
A:Yes, we can.
Q7: What's your guarantee?
A: All our products have 6 months guarantee after received goods, if any quality problem please contact us.
Q8: What's your delivery time ?
A: The common delivery time is 5-25 days. The specific delivery time depends on the items and the quantity of your order.
Q9: What's your minimum order quantity?
A: The MOQ is 150 kg.
P.S : Keep the dry environment,and is better use it in 30days.
