10 Micron Lithium Ion Battery Copper Foil / Ed Copper Foil High Performance
Price:
negotiation
MOQ:
20kgs
Delivery Time:
5-15 days
Brand:
JIMA
Product Description
10 micron lithium battery copper foil,ed copper foil
Detail
> Thickness:6micron,7micron,8micron,9micron,10 micron,12micron
> Width :530mm,200mm,600mm ,max.1380mm,small size can be cutting as request.
> copper foil for lithium battery current collector
> small quantity can be supply
> A4 sample can be supply
> Matercial Technical data can be supply
Lithium Battery Copper Foil Techncail Data
| Classification | Unit | Requirement | Test Method | |||||||
| Foil Designation | / | IPC-4562A | ||||||||
| Nominal thickness | / | 6um | 7um | 8um | 9/10um | 12um | 15um | 20um | IPC-4562A | |
| Area Weight | g/㎡ | 54±1 | 63±1.25 | 72±1.5 | 89±1.8 | 107±2.2 | 133±2.8 | 178±3.6 |
IPC-TM-650 2.2.12.2 |
|
| Purity | ％ | ≥99.9 |
IPC-TM-650 2.3.15 |
|||||||
| Foil Profile | Shiny side (Ra) | um | 0.1-0.4 |
IPC-TM-650 2.3.17 |
||||||
| Matte side(Rz) | um | 0.8-2.0 | ||||||||
| Tensile Strength | R.T.(23℃) | Mpa | ＞280 |
IPC-TM-650 2.3.18 |
||||||
| H.T.(180℃) | ＞200 | |||||||||
| Elongation | R.T.(23℃) | ％ | ＞5 |
IPC-TM-650 2.3.18 |
||||||
| H.T.(180℃) | ＞3 | |||||||||
| Pinholes&porosity | Number | No |
IPC-TM-650 2.1.2 |
|||||||
| Anti-oxidization | R.T.(23℃) | day | 90 | / | ||||||
| H.T.(160℃) | Minutes | 15 | / | |||||||
RFQ
Lithium Battery Copper Foil Pictures
Copper Foil Packing Pictures
