Matte Side Treatment Very Low Profile Copper Foil 10um 12um 18um 25um 35um
Price:
Negotiation
MOQ:
50kg
Delivery Time:
5-15 days
Brand:
JIMA
Product Description
Matte Side Treatment Very Low-Profile Copper in Black/Red (VLP-S-B/R)
The raw foil, which has a glossy surface with ultra low roughness on both sides, is treated with JIMA's proprietary micro-roughening process to achieve high anchoring performance and also ultra low roughness. It offers high performance in a wide range of fields, from rigid printed circuit boards that prioritize transmission properties and fabrication of fine pattern to flexible printed circuits that prioritize transparency.
Detail:
- Core Length: as request
- Nominal thickness:10um 12um 18um 25um 35um
- Core Material: Paper and ABS plastic & Customize
- Sample:Can be supply
- Inner Package: can supply Vacuum packaging if need
- Roll Length/Outer diameter/Inner diameter: as request
Features:
- Low profile for FCCL
- Grain structure of copper foil leads to high flexibility
- Excellent etching performance
- The treated foil is red or black
- Low profile enables to make fine circuit pattern
Typical Application
- Casting and lamination type FCCL
- Fine pattern FPC&PWB
- Chip on flex for LED
- For FPC or Inner layer
- For a wide range of applications, from circuit boards to optics.
Typical Properties of Matte Side Treatment Low Profile Copper Foil
| Classification | Unit | Requirement | Test Method | |||||
| Nominal thickness | um | 10 | 12 | 16 | 25 | 35 | IPC-4562A | |
| Area Weight | g/m² | 98±4 | 107±4 | 153± 5 | 228± 8 | 285±10 | IPC-TM-650 2.2.12.2 | |
| Purity | % | ≥99.8 | IPC-TM-650 2.3.15 | |||||
| Roughness | Shiny side (Ra) | սm | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | IPC-TM-650 2.3.17 |
| Matte side(Rz) | um | ≤4.0 | ≤4.5 | ≤5.5 | ≤6.0 | ≤8.0 | ||
| Tensile Strength | R.T.(23°C) | Mpa | ≥260 | ≥260 | ≥280 | ≥280 | ≥280 | IPC-TM-650 2.4.18 |
| H.T.(180°C) | ≥180 | ≥180 | ≥180 | ≥180 | ≥180 | |||
| Elongation | R.T.(23°C) | % | ≥5 | ≥6 | ≥8 | ≥10 | ≥12 | IPC-TM-650 2.4.18 |
| H.T.(180°C) | ≥5 | ≥6 | ≥7 | ≥8 | ≥8 | |||
| Peel Strength(FR-4) | N/mm | ≥0.7 | 0.8 | 1.0 | 1.1 | 1.2 | IPC-TM-650 2.4.8 | |
| lbs/in | ≥4 | ≥4.6 | ≥5.7 | ≥6.3 | ≥6.9 | |||
| Pinholes & Porosity | Number | No | IPC-TM-650 2.1.2 | |||||
| Anti-oxidization | R.T.(23°C) | 180 | ||||||
| R.T.(200°C) | 60 | |||||||
Standard Width: 520mm 1040mm 1100mm, Max.1300mm May according to the customer request tailor.
