High head horizontal multistage electric centrifugal water pump China factory price

High head horizontal multistage electric centrifugal water pump China Gempump

D horizontal multistage electric water pump is an energy-saving product series performance parameters and technical data are higher. 8 inch horizontal multistage electric water pump is suitable for the circulation and pressurization of cold and warm clear water in high-pressure operation system, water supply under parallel operation of several pumps in civil construction, water supply for fire control, boiler, cooling water system and the delivery of various liquid.

Basic performance data

Pump Application:

• long distance water transferring
• boiling water feeding and transferring
• water system boosting
• agricultural irrigation
• mining water supply
• fire fighting
• offshore projects
• Technical Data:

•

  Model	Capacity (m³/h)	Head (m)	Speed (rpm)	Motor Power (kw)	Impeller Dia (mm)
  6-25*5	6.3	125	2950	7.5	139
  6-50*4	6.3	200	2950	18.5	198
  12-25*4	12.5	100	2950	11	146
  6-80*3	6	240	2950	18.5	235
  12-80*4	12.5	320	2950	45	235
  25-30*3	25	90	2950	15	160
  46-30*5	46	150	2950	37	162
  85-67*4	85	268	2950	110	235
  120-50*5	120	250	2950	132	213
  150-30*8	150	240	2950	160	172
  150-100*6	150	600	2950	400	289
  200-100*6	200	600	2950	560	290
  280-65*6	280	390	1480	500	430
  300-45*4	300	180	1480	200	360
  150D30*6	155	180	1480	132	305
