50-200mm PVC Pipe Extrusion Line / PVC Pipe Making Machine / PVC Pipe Production Line
Price:
USD EUR
MOQ:
1 SET
Delivery Time:
30 WORKING DAYS
Brand:
LB
Product Description
PVC Pipe Extrusion Line
Complete production line for PVC/UPVC pipe ranging from 16mm to 800mm diameter. This versatile system produces pipes for electrical conduit, agricultural, and construction applications with varying diameters and wall thicknesses.
Applications
UPVC pipes are widely used in industrial and daily life applications including:
- Electrical conduit systems
- Water supply and sewage pipelines
- House decoration and construction
- Chemical transportation
- Gas distribution networks
Features include high strength, structural integrity, excellent chemical resistance, durability, thermal stability, non-toxic safety, low maintenance, and cost-effectiveness.
Production Process
PVC powder + additive → mixing → material feeder → twin screw extruder → mould and calibrator → vacuum and cooling tank → spraying cooling machine → haul-off machine → cutting machine → discharge rack or pipe belling machine.
Specifications
| Model/Data | Pipe Diameter | Extruder Model | Speed | Max Capacity |
|---|---|---|---|---|
| LB-63 | 16-63mm | LB-51/105 | 1-10m/min | 120kg/h |
| LB-160 | 75-200mm | LB-65/132 | 1.5-5m/min | 260kg/h |
| LB-400 | 200-400mm | LB-80/156 | 0.5-1.5m/min | 400kg/h |
| LB-630 | 400-630mm | LB-92/188 | 0.1-0.8m/min | 650kg/h |
Component Details
Mixer
Specialized design reduces raw material self-friction, improving energy utilization efficiency. Features vacuum suction load with low noise and dust-free operation.
Twin Screw Extruder
Crafted with top brand components for production stability, efficiency, and durability. Conical twin screw design ensures homogeneous mixture, better plastification, and superior conveying efficiency.
Vacuum Calibration & Cooling
Two-chamber structure with vacuum calibration and cooling sections. Both vacuum and spraying cooling tanks use stainless 304 steel. Excellent vacuum system ensures precise pipe sizing.
Haul-off Unit
Three crawler track system ensures stable and steady pipe operation. Hauling models can be tailored to specific production requirements through general control adjustments.
Cutting Unit
High-accuracy encoder provides precise and stable cutting lengths. PLC control system enables manual operation cutting based on specific application needs.
Technical Features
- Plastic pulverizer easily grinds all types of Hard & Soft PVC into powder
- Dust collector effectively reduces dust pollution
- Main fan discharging reduces operator labor intensity
- Host door cover opens for convenient maintenance and cutter replacement
- Water and wind double cooling system prevents bearing and component overheating
- Adjustable powder mesh (15-100 mesh)
- Easy installation and maintenance with door access for cleaning
- Well-known brand accessories including motors for long-term operation
- Wide range of optional accessories for customized solutions based on budget and requirements
Extrusion Line Details
Final Product Examples
