UL2103 TYPE PVC Tinned Copper Stranded 20P×26AWG ( 7/0.16T )+ AB 105℃ 300V Cable
| Construction | ||||
| Conductor | Tinner copper stranded | |||
| Cross section | 26AWG | |||
| Construction | 7/0.16mm | |||
| Strand Dia. | 0.48mm | |||
| Insulation | SR-PVC | |||
| Nom.Thickness | 0.23mm | |||
| Min.Thickness | 0.18mm | |||
| Insulation Dia. | 1.00±0.08mm | |||
| Insulation colour | See the colour table | |||
| Twisted | 2.00mm | |||
| Material 1 | Al-mylar(fcae in) | |||
| Filler | Optional | |||
| Material 2 | Al-mylar(face out) | |||
| Assembly | 20×(1P×26AWG+A)+A | |||
| Braid | Tinner copper,0.10mm,≥65% | |||
| Jacket | PVC | |||
| Nom.Thickness | 0.76mm | |||
| Min.Thickness | 0.61mm | |||
| O.D. | 12.20±0.40mm | |||
| Colour | Per request | |||
| Colour table | |||||
| 1 | white&black | 18 | black&grey | ||
| 2 | white&brown | 19 | black&pink | ||
| 3 | white&red | 20 | brown&red | ||
| 4 | white&orange | ||||
| 5 | white&yellow | ||||
| 6 | white&green | ||||
| 7 | white&blue | ||||
| 8 | white&violet | ||||
| 9 | white&grey | ||||
| 10 | white&pink | ||||
| 11 | black&brown | ||||
| 12 | black&red | ||||
| 13 | black&orange | ||||
| 14 | black&yellow | ||||
| 15 | black&green | ||||
| 16 | black&blue | ||||
| 17 | black&violet | ||||
Products are used in communication equipment, instruments, industrial control systems, electronic and electrical equipment.
- Application: For internal wiring of electronic equipment and appliance
- Application standard: UL758 & UL1581 & CSA C22.2 No.210
- Excellent insulation performance, stable chemical properties
- Pass UL VW-1 and CSA FT1 vertical flame test
- Heat resistance, anti-acid and environmental protection
- Tinned or bare copper, stranded or single conductor, 26AWG
- SR-PVC insulation
- Two or more single-core wires twisted into pair or cabling
- Tinned or bare copper wire, spiral or braid shield or Al-mylar wrapped shield
- PVC jacket
- Rated temperature: 105ºC
- Rated Voltage: 300V,
| Mechanical Performance | ||||||||
| Jacket | ||||||||
| Material | PVC | |||||||
| Tensile strength | ≥10.3MPa | |||||||
| Elongation | ≥100% | |||||||
| Aged condition | 136±1℃×168h | |||||||
| Percent of original tensile strength | ≥70% | |||||||
| Percent of original elongation | ≥65% | |||||||
