Popular 3m Width 10m Length 60t Heavy-Duty Truck Scales Weighing Weight Bridge Smooth Plate Or Checker Plate Platform
High quality popular 3m width 10m length 60t Heavy-Duty truck scales price weighing weight bridge
Advantages:
1. Accurate: division is 10kg
2. Durable: over 10 years of service life for normal operation
3. High standard, OEM available
4. Reasonable Price
Composition:
1. High-accuracy OIML approved Load Cells
2. Indicator
3. Weighing Platform
4. Junction box
5. All bolts and nuts are included.
| size | Length of module | QTY of Module | Load cell Qty. |
| 3X6 | 1.5x6m | 2 | 4 |
| 3X8 | 1.5x4m | 4 | 6 |
| 3X9 | 1.5x4.5m | 4 | 6 |
| 3X10 | 1.5x5m | 4 | 6 |
| 3X12 | 1.5x6m | 4 | 6 |
| 3X15 | 1.5x5m | 6 | 8 |
| 3X16 | 1.5x5.33m | 6 | 8 |
| 3X18 | 1.5x6m | 6 | 8 |
Description:
1. Supply status: steel frame in H300 steel, more convenient for container
transportation and economic for transportation charge
2. Reinforcement bars to be welded at the customer's site.
3. With OIML R60 approved double shear beam load cells, KELI QS-30t or ZEMIC HM9B-30t
4. Width available: 3m,3.2m,3.4m
5. Standard length available:6m,7m,8m,9m,10m,12m,14m,16m,18m,20m,21m,24m
6. Max.Capacity available: 30t,40t,60t,80t,100t,120t
7. In one 40'container,7 pcs of 18m can be loaded in.
Applications:
1). Weighing
2). Net weight/tare
3). Weight accumulation
Competitive Advantage:
1. We develop this export style structure, suitable for container transportation, and becomes the most popular export style structures in China market.
2. Our engineer has the unique designing ideas for this structure that the other imitators cannot imitate, which makes our truck scales with the best ratio between the quality and price.
3. Easy installation, robust structure.
