Single Jet Water Fountain Nozzles Stainless Steel DN20 / DN80 Connection
SINGLE JET WATER FOUNTAIN NOZZLE DN20-DN80 IN STAINLESS STEEL
adjustable jets are the most popular nozzles in fountain project. They could produce full stream, glass clear and flowing single jet. The incline of installing the adjustable nozzles could create the interesting water effects. Many water jets group together could create many kinds of water paterns. Single jet nozzles are simple structure and widely used. There are fixed and universal adjustable types.
TECHNICAL DATA SHEET :
| Model | connection | Pressure (Kpa) | Flow rate (m3/h) | Discharge Height (M) | Coverage diameter (m) |
| ASF15 | DN15 | 15-65 | 0.3-1.5 | 1.0-4.0 | Para-curve |
| ASF20 | DN20 | 15-80 | 1.0-3.0 | 1.0-5.0 | Para-curve |
| ASF25 | DN25 | 50-100 | 2.0-4.0 | 3.0-6.0 | Para-curve |
| ASF40 | DN40 | 50-150 | 3.0-6.0 | 3.0-7.0 | Para-curve |
| ASF50 | DN50 | 50-200 | 5.0-8.0 | 3.0-8.0 | Para-curve |
| ASF65 | DN65 | 70-250 | 10.0-25.0 | 3.5-15.0 | Para-curve |
| ASF80 | DN80 | 70-330 | 10.0-40.0 | 3.5-20.0 | Para-curve |
| ASF100 | DN100 | 80-400 | 10.0-60.0 | 3.5-25.0 | Para-curve |
Remark :
1) water outlet can be made bigger as per customer’s request.
2) valve can be added to nozzle to control discharge flow and height to acheave all kinds of water pattern.
