IP68 Recessed LED Underwater Lights 45W~80W Made Of 316 Stainless Steel For Wall Or Ground recessed mounted and Pool Or Pond Lighting
Price:
Negotiable
MOQ:
No MOQ
Delivery Time:
10-25days
Brand:
COMI
Product Description
IP68 Recessed LED Underwater Lights 45W~80W
Made of 316 stainless steel for wall or ground recessed mounting in pools, ponds, and water features.
Product Overview
COMI LIGHTING IP68 SUS316 stainless steel recessed LED underwater pool lights are constructed from SUS 316L# stainless steel, making them ideal for atmospheric or underwater lighting in fountains, pools, ponds, and water gardens.
Key Features & Benefits
- Lamp Body Size: Φ250xH150mm
- Light Source Options:
- SMD LED version: 24pcs x 2W single, 3W RGB 3-in-1 LED, or 4W RGBW 4-in-1 LED
- COB LED Version: 1 piece 45W CREE COB LED
- Input Voltage: 24Vdc operating voltage
- Power Consumption: 45W or 48W (Mono), 60W (RGB 3-in-1), 80W (RGBW 4-in-1)
- Completely stainless steel SUS 316 L# housing & accessories
- Standard non-dimmable, with optional DALI, 1-10V, PWM Dimmable or DMX 512 controllable
- IP68 waterproof rating, suitable for underwater installation up to 1 meter depth
- High-performance silicone for effective heat radiation and moisture prevention
- SUS 316 stainless steel mounting sleeve included
- 2 Years warranty
Important Installation Notes
- Water must be allowed to flow freely inside and outside the sleeve without leaking from the other side
- This IP68 SUS 316 L# stainless steel luminaire must be installed underwater to prevent overheating and potential damage
Material Specifications
| Component | Specification |
|---|---|
| Front Cover & Housing | Molding shaped SUS 316 L# stainless steel housing |
| Gasket | EPDM gasket |
| Window Glass | Step tempered glass, T=10mm |
| Glass Pressure Capacity | Full area = 5012 KGs |
| Lens | Optical lens, efficiency ≥ 85% |
| Cable Gland | IP-68 PG-11 copper with nickel-coated |
| PCB | Excellent heat conductivity aluminum, coefficient ≥ 2.0w/mk |
| Driver | Constant current output |
| Application Environment | Water temperature between -20℃~40℃, depth less than 1 meter |
| Electrical Connection |
|
| Installation | PVC plastic mounting sleeve (included) |
| Control Options | Standard non-dimmable, optional DALI, 1-10V, PWM Dimmable or DMX 512 controllable |
Technical Specifications
| Part Number | Light Source | Light Color | Lens Degree | Input Voltage | Power Consumption | Luminance | IK Rate |
|---|---|---|---|---|---|---|---|
| B4BF0150 | 1×50W CREE COB LED | 2700~6500K | 15°, 24°, 36°, 60° | 24VDC | 45W | Cool white=4275LM Warm white=3548LM |
10 |
| B4BF2456 | 24×1W Osram or Cree Single color LED | Single Color | 10°, 25°, 40°, 60°, 80°, 10×45°, 25×45° | 24VDC | 24W | Cool white=1728LM Warm white=21434LM |
10 |
| B4BF2457 | 24×2W Osram or Cree Single color LED | Single Color | 10°, 25°, 40°, 60°, 80°, 10×45°, 25×45° | 24VDC | 48W | Cool white=3456LM Warm white=2868LM |
10 |
| B4BF2418 | 24×2.5W RGB 3-in-1 Full color LED | RGB | 25°, 40°, 60°, 80°, 10×45°, 25×45° | 24VDC | 60W | 1500LM | 10 |
| B4BF2420 | 24×3.5W RGBW 4-in-1 Full color LED | RGBW | 25°, 40°, 60°, 80°, 10×45°, 25×45° | 24VDC | 80W | 2800LM | 10 |
Note: Specifications are subject to change without notice.
