C4FB1857 C4FB1818 RGB Dimmable Recessed Underwater LED Lights Made of SUS316 Stainless Steel Anti Corrosion
C4FB1857, C4FB1818(RGB) 18 * 2W or 3W High Power Osram LED Dia. 250mm Asymmetrical Dimmable LED Underwater Pool Lights, Wall Recessed Pool Lamp
Features and Benefits:
1. 18pcs 2W Osram or 3W 3-in-1 RGB Full Color High power LED as its light source;
2. Big size diameter 250mm front cover;
3. High brightness output 2290-2980lm;
4. Anticorrosion Completely stainless steel SUS 316L# moulding Housing to meet hash envirenment;
5.Use the Silcone with good stickiness and thermal effect for reach the purpose of radiating and prevent moisture.
Must be installed underwater to prevent the light from burning up because of over-heating.
| Front Cover and Housing | Molding shaped hard chromeplated stainless steel SUS 316L # |
| Light Window | Step tempered glass.T=10mm |
| Gasket | Silicone Gasket |
| Optical lens | 45°|35° Optical lens,efficiency≥85% |
| Glass pressure capacity | Full area=5012kgs |
| PCB | Excellent heat conductivity aluminum. coefficient of heatConductivity≥2.0w/mk |
| Cable gland | IP-68 PG-11 copper with nickel-coated |
| LED Driver | Constant Voltage Input, Constant Current Output |
| Power Cable |
H07RN-F 2X1.0mm² L=3.0m(Single Color); H07RN-F 4X0.75mm² L=3.0m(RGB) |
| Application environment | Temperature of water between -20˚C~40˚C less than 1 meter depth. |
| Mounting sleeve | ABS |
| Dimmable Support | Triac PWM 1-10V Dali |
Technical Specification:
| Item No. | Light source | Lens |
Degree
(Θ 1 / 2 )
|
Input
voltage
(V)
|
Typical
operating
current (mA)
|
Typical
Power
(w)
|
Typical
Luminance
(lm)
|
IK rate |
| C4FB1857 |
18×2W
Single Color
|
C8 | 45°|35° | 24VDC | 1900 | 40 |
Cool white=2905
Warm white=2298 |
10 |
| C4FB1818 |
18×2W
3-in-1 RGB
Full Color
|
C8 | 45°|35° | 24VDC |
R=630
G=770 B=770 |
50 | 990 | 10 |
Notes:
Dimensional Drawing(units:mm):
