10 Pin Common Cathode Single Digit 0.39inch 7 Segment LED Display with 10000hours Life Span and 620-625nm Wavelength for Instrument Panel
- Package dimension: 10*13*7mm
- Character height: 9.9mm (0.39 inch)
- Polarity: Common cathode
- Colour: Super bright red
- Face Colour: Black/Grey
- Wavelength: 630-635nm
- Luminous intensity: 50-60mcd/dice
- Forward voltage: 1.8-2.2V/led
- Available colors: red, blue, yellow green, pure green, white, amber, orange, and yellow
| Parameter | Symbol | Ratings | Unit |
|---|---|---|---|
| Forward Current (per dice) | Ipm | 20 | mA |
| Reverse Voltage (per dice) | Vr | 5 | V |
| Power Dissipation (per dice) | Pm | 80 | mW |
| Operating Temperature Range | Topr | -40~+85 | ºC |
| Storage Temperature Range | Tstg | -40~+85 | ºC |
| Solder Temperature (≤3 seconds) | Th | 260 | ºC |
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
|---|---|---|---|---|---|---|
| Forward Voltage | Vf | If=10mA | 1.8 | 2.4 | V | |
| Reverse Voltage | Vr | Ir=10uA | 5 | V | ||
| Luminous Intensity | Iv | If=10mA | 30 | 40 | mcd | |
| Spectrum Width Of Half Value | △λ | If=10mA | 20 | nm | ||
| Wavelength | Dλ | If=10mA | 569 | 574 | nm |
7 Segment LED Display, Customized LED Display, Numeric LED Display, Dot matrix LED Display, widely used for:
- Home appliances
- Temperature indicators
- Humidity indicators
- Refrigerator controllers
- Thermostat indicators
- Heating and cooling control systems
A: We are original manufacturer with more than 20 years experience in optoelectronic LED displays.
A: Our main products include 7 Segment LED display, SMD LED Display, Dot matrix LED Display, Arrow LED display, Custom Design LED Display, LED light bar, Through hole led, SMD LEDs, LED Backlights, and more.
A: Our MOQ is 1000 pcs, but we can also accept sample orders and small orders with quantity less than our MOQ.
A: Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
A: Delivery time is about 10-20 days, depending on order quantity and raw materials. For urgent orders with available materials, we can adjust production to deliver within 7-10 days.
A: We accept bank transfer, T/T, Western Union and Paypal for small amounts. Payment methods are negotiable.
A: Yes. We can quote prices based on incoterms EXW, FOB, CIF, DDP.
A: Please provide your email address or contact us directly through our website for our catalogue and price list.
A: Yes, we may consider discounts for bulk orders.
A: Shipping charges depend on shipment size and method. We will provide charges upon request.
A: Yes, OEM & ODM services are available. We can customize sizes, LED colors and functional icons according to your requirements.
A: Yes, we will not show or sell your design to others without your authorization.
A: Sample lead time is about 20-25 working days after receiving mold cost and approved mold drawings.
A: We typically ship via DHL, FedEx, UPS, EMS, by air or by sea. Other methods can be arranged.
A: As ISO 9001 certified manufacturers with 20+ years experience, we conduct two 100% tests on all products before shipment.
