High Impact Resistant Pvc Garage Wall Panels For Indoor Decoration Marble Color bamboo fiber wall panel
40cm width hot stamping high impact resistant garage pvc wall panels marble color
PVC panel is an new system of light weight construction for ceiling and wall, its assembly system always offer elegance and different finishes. PVC panels for ceiling and wall are widely used for indoor decorative.
40cm width pvc garage wall panels, it is very tough, the flat is smooth, matt marble color, washable surface and easy to intall, it is popular for Canada and America markets.
Features and Benefits of garage pvc wall panels:
• CFAI approved
• PVC flat profile panel with coordinating trims and corners
• The economical alternative to other interior panel systems
• Can be used for both walls and ceilings
• Attractive high-gloss white finish giving superior light reflectance
• Extremely light weight – very high strength to weight ratio
• Excellent impact resistance – resists breaking, scuffs and scratches
• Easy to clean
• Easy to install using common equipment
• Hidden fastener system eliminates unsightly areas where dirt and bacteria can collect
• Excellent chemical resistance
• Will not corrode
• 20 Year Limited Warranty against deterioration, loss of rigidity
• Complements with other interior products
Application of our high impact resistance pvc garage wall panels:
our 40cm garage wall panels, it is smooth,tough, cost-effective solution for interior walls and ceilings
Easy to work with and to install, that is perfect for the interior walls or ceilings in your agricultural, commercial or industrial buildings. yet resistant surface is the ideal solution for applications such as:
1, Hog, poultry and dairy containment buildings
2, Farm storage buildings
3, Chemical processing and storage facilities
4, Refrigerated warehouses
5, Car washes
6, Many more uses where a tough, chemically resistant interior is needed
7, Even the inside of your own residential garage
Fire test report of pvc wall panels:
|
Report No. |
V03 |
Specification |
400×9mm |
||||
|
Product |
PVC Wall Panel |
Standard |
BS EN 13501-1:2007 |
||||
|
Test Items |
Measure Unit |
Technical Requirement |
Test Results |
Individual Judgment |
|||
|
Fire growth rate index (Figra) |
W/s |
C |
≤250 |
105 |
Compliant |
||
|
Lateral flame spread ( LFS) |
m |
<edge of specimen |
Yes |
Compliant |
|||
|
Total heat release within 600 s(THR 600s) |
MJ |
≤15 |
11.5 |
Compliant |
|||
|
Flame spread (Fs) |
Surface |
mm |
≤150 |
30 |
Compliant |
||
|
Edge |
33 |
Compliant |
|||||
|
Smoke growth rate (SMOGRA) |
m2/s2 |
S2 |
≤180 |
192 |
S3 Compliant |
||
|
Total smoke production within 600 s(THR 600s) |
m2 |
≤200 |
666 |
||||
|
Flaming droplests/particles |
------ |
d0 |
No flaming droplets/particles occur within 600s |
Yes |
Compliant |
||
|
Ignition of the filter paper |
------ |
No ignition of the filter paper |
Yes |
Compliant |
|||
|
Conclusion |
The combustion performance of sample is satisfied BS EN 13501-1:2007 about grade C-s3,d0. |
||||||
EST REPORT (TEST REQUIREMENT: QB/T2133-1995,Q/HSJ 01-2005)
| Item | Technical requirements | Results of inspection | Verdict | |
| 1 | Bending | ≤3.0 | 0.56 | Pass |
| 2 | Length deviation | Not allowed negative deviation | Pass | |
| 3 | Dimensional stability after heating % | ≤6.0 | 0.50 | Pass |
| 4 | Dimensional stability from high and low temperatures % | ±0.4 | -0.07 | Pass |
| 5 | Tolerance of acid | No defect | Pass | |
| 6 | Strike by drop hammer | 0.5kg/1 m | Pass | |
| 7 | Tolerance of driving nail | No crack | Pass |
