Railway Vinyl Coated Wire Mesh Fence With Low Carbon Steel / Powder Spray Coating
Plastic Welded Wire Mesh Fence After Galvanized For Railway Fencing
The Plastic Welded Wire Mesh Fence is welded with high quality low carbon steel wire, surface treated by electrostatic powder spray coating over galvanized materials. |
It's used as Boundary and Security Fence in airport , highway , stadium , etc. |
It can resist the corrosive and ultraviolet very strongly, each fencing panels comes with a single post, hence an extra end post is required to finish a run. |
The post type could be round post, square post or peach post . |
The wire mesh fence is custom made by our factory, each fence panel comes with a post and accessories .
Feature:
- simple structure
- nice appearance
- Wide view and easily installation.
- It’s a semi-opaque fence due to the open weave
- It not obscure sunlight from either side of the fence
- thoroughly sealed and protected against rust and corrosion
Usage: Wire Mesh Fence is used for: security and isolation of highway fencing , stadium fencing , machine protection , green belt fencing , zoo fencing , courtyard fencing, industry zone fencing , decoration, etc.
Road and Transit ( Highway, Railway, Road, City Transit ) |
Public grounds ( Park, Zoo, Train or Bus Station, Lawn ) |
Science Industry Zone ( Industry Zone, Sightseeing Zone, New pattern farm ) |
Private grounds ( Courtyard, Villa ) |
Commercial grounds ( Corporation, Hotel, Supermarket ) |
Quick Detail:
Specification of wire mesh fence | |||
Mesh Opening | 50x100, 50x150, 50x200,55x100,55x200 | mm | |
Panel Size | 2x0.63, 2x0.83, 2x1.03, 2x1.23, 2x1.43, 2.5x1.63, 2.5x1.83, 2.5x2.03, 2.5x2.23, 2.5x2.43 | m(L x H) | |
Post Size | 50x70, 70x100, 50x50, 60x60, (square hole) φ32,36,38,40,42,48(round post diameter) | mm | |
Wire Diameter | 3-6mm as customer’s request | mm | |
Surface Color | Green, blue, black, white, yellow,etc. | ||
Post Type | Peach post, square. Holland, T-type, Y-type post | ||
Modular fencing system | Panel size (L*H) mm | Post height mm | Number of bending folds |
2405*1270 | 1500 | 2 | |
2405*1570 | 1850 | 2 | |
2405*1720 | 2130 | 2 | |
2405*2000 | 2450 | 3 | |
Surface Treatment could be Galvanized or PVC coated. NOTE: There’re common specifications of products. Non-standard can also be customized as customer's request.
| Post Type | Post Size |
| Square Post | 50x70mm, 70x100mm, 50x50mm, 60x60mm |
| Round Post | 32mm, 36mm, 38mm, 40mm, 42mm, 48mm |
| Peach Post | 50x70mm, 70x100mm |
Production Process: Wire Drawing → Wire Straightening & Wire Cutting → Welding → Folds / Curves Bending → Electric Galvanizing / Hot-dipped Galvanizing → Parkerizing → PVC Coating / Spraying → Packing → Loading
FAQ: 1. I'm interested in your product, is custom size available? Yes, our factory is professional in producing kinds of wire mesh, the product could be customized as your request . 2. The quantity is not that big, is that OK? Yes, you can send us message with the real quantity, we'll try our best to make this order for you. We'd like to make good relationship with more customers. 3. Can I get free samples? Yes, we'd like to provide small pieces free samples, and customers pay for the express fee. 4. Can you provide OEM service? Yes, all the products can be made as your require.
