CPM2513 200*300*118mm Concrete Mixer Truck Bearing
Price:
Ask
MOQ:
1
Delivery Time:
7-35 days
Brand:
MONTON
Product Description
CPM2513 200*300*118mm Concrete Mixer Truck Bearing
Technical Data of CPM 2513
| Bearing Part |
CPM 2513 |
| Bearing type: | Concrete Mixer Truck Bearing |
| Seal type: | Open |
| Row type | Double row |
| Cage type | steel cage |
| Dimension: | 200x300x118mm |
| Bore / d (mm) | 200mm |
| O.D/D(mm) | 300mm |
| Width/T(mm) | 118mm |
| Weight(kg) | 19.5kg |
| Brand: | MONTON |
Concrete Mixer Truck Reducer Bearing CPM2513 have two spherical rollers, the outer ring raceway is in spherical shape. This bearing has a function of automatic self-aligning, so can compensate the error caused by the axial deformation or housing units. The roller and raceway of the Concrete Mixer Truck Reducer Bearing CPM2513 are for line contact, then the bearing can stand a bigger radial load and axial load.
