HASL LF Printed Circuit Board Assembly 1.6mm 6 Layer FR4 Green Soldermask pcb electronics
FR4 Multilayer Electronic Circuit Board Assembly Blue Soldmask 1oz Copper
PCB Electronic Circuit Board Assembly SMT
1. Features
1. One Stop OEM Service, Made in Shenzhen of China
2. Manufactured by Gerber File and BOM List from Customer
3. FR4 Material, Meet 94V0 standard
4. SMT, DIP technology suport
5. Lead Free HASL, Environmental Protection
6. UL, CE, ROHS Compliant
7. Shipping By DHL,UPS, TNT, EMS or Customer requirement
2. PCBA Technical capability
|
SMT Manufacturing Capability
|
|||
|
Item
|
Manufacturing Capability in process
|
Manufacturing Method
|
|
|
Production size(Min/Max)
|
50×50mm / 500×500mm
|
|
|
|
Production board thickness
|
0.2 ～ 4mm
|
|
|
|
Printing solder paste
|
Support method
|
|
Magnetism fixture, vacuo platform
|
|
|
|
Sticking up by vacuo, clamping on both sides ,flexible clamping with sheet, flexible clamping with thick board
|
|
|
Cleaning Method of printing solder paste
|
|
Dry method+ wetting method+ Vacuo method
|
|
|
Accuracy of printing
|
±0.025mm
|
|
|
|
SPI
|
Repeated accuracy of volume
|
<1% at 3σ
|
|
|
Mounting component
|
Components size
|
0603(Option) L75mm Connector
|
|
|
Pitch
|
0.15mm
|
|
|
|
Repeated accuracy
|
±0.01mm
|
|
|
|
AOI
|
FOV size
|
61×45mm
|
|
|
Test speed
|
9150mm²/Sec
|
|
|
|
3D X-ray
|
Shootingangle
|
0-45
|
|
3 . Specification Of PCB Assembly Service
| 1 | Layer | 1-30 layer |
| 2 | Material | FR-4, CEM-1, CEM-3, Hight TG, FR4 Halogen Free, FR-1, FR-2, Aluminum |
| 3 | Board thickness | 0.2mm-7mm |
| 4 | Max.finished board side | 500mm*500mm |
| 5 | Min.drilled hole size | 0.25mm |
| 6 | Min.line width | 0.075mm(3mil) |
| 7 | Min.line spaceing | 0.075mm(3mil) |
| 8 | Surface finish/treatment | HALS/HALS lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating |
| 9 | Copper thickness | 0.5-4.0oz |
| 10 | Solder mask color | green/black/white/red/blue/yellow |
| 11 | Inner packing | Vacuum packing, Plastic bag |
| 12 | Outer packing | Standard carton packing |
| 13 | Hole tolerance | PTH:±0.076, NTPH:±0.05 |
| 14 | Certificate | UL, ISO9001, ISO14001, ROHS, CQC |
| 15 | Profiling Punching | Routing, V-CUT, Beveling |
| 16 | Assembly Service | Providing OEM service to all sorts of printed circuit board assembly |
4. PCBA Pictures
Products Application:
1, Telecom Communication
2, Consumer Electronics
3, Security monitor
4, Vehicle Electronices
5, Smart Home
6, Industrial controls
7, Military & Defense
8, Automotive
9, Smart Home
10, Industrial Automation
11, Medical Devices
12, New Energy
And so on
