High Quality Galvanised Steel Grating Stainless Steel Carbon Steel Drain Trench Water Grate Covers for Industrial Flooring
High-grade steel grating is typically pickled afterproduction to remove scale and discoloration caused bywelding, which can lead to corrosion. During the picklingprocess, the grating is submerged in a bath that cleansesthe surface, leaving it metallically pure and corrosion-resistant.
Hot-dipped galvanized steel grating involves submergingthe steel grating in molten zinc, a process calledgalvanization. This forms a strong metallurgical bondbetween the zinc and the steel, resulting in a durable.corrosion-resistant protective layer.
Powder coating is a cost-effective, durable way to colorgrating. The process includes degreasing, pickling, zinc.phosphating, and electrostatic powder application, thenbaking at 180°C.For enhanced corrosion protection, thiscoating combines hot-dip galvanizing with powder coatingAvailable in all RAL colors, with different gloss levels andtextures.
|
Material
|
Carbon Steel, Stainless Steel, Aluminum
|
|
|
Surface treatment
|
Hot dipped galvanized, Spray painting, Polished and powder coated
|
|
|
Bearing bar type
|
Plain(Flat) bar, Serrated bar, I-bar, etc.
|
|
|
Common specification
|
||
|
Bearing bar pitch (mm)
|
Cross bar pitch (mm)
|
Bearing bar size
(WSG_Height×Thickness_Bearing bar pitch_Cross bar pitch) |
|
30
|
100
|
WSG_203/253/323/403/205/325/405/455/505/555_30_100
|
|
|
50
|
WSG_203/253/323/403/205/325/405/455/505/555_30_50
|
|
40
|
100
|
WSG_203/253/323/403/205/325/405/455/505/555_40_100
|
|
|
50
|
WSG_203/253/323/403/205/325/405/455/505/555_40_50
|
|
60
|
50
|
WSG_203/253/323/403/205/325/405/455/505/555_60_50
|
|
If you have any questions regarding the dimensions or specific specifications, please feel free to contact us immediately.
|
||
