Mini Expanded Metal Mesh Thickness 0.8mm Punching Sliver ISO9001 approval
Hot Dipped Galvanized Expanded Metal Sheet Low Carbon Steel
1. Description
1>Material:stainless steel,aluminum,low carbon steel(pvc coated,galvanized,painted)
2>Technique: punched hole,then drawing.
2. Application
galvanized expanded metal mesh in buildings and construction, maintenance of equipments, making of arts, covering screen. Also fencing for super highway, studio, highway. Heavy expanded metal can be used as step mesh of oil tanks, working platform, corridor and walking road for heavy model equipment, boiler, big ships. Also serve as reinforcing bar in construction, railway and bridges.
3. Specification
| Material |
high quality low carobon., hot-rolled steel, hot galvanized plate, stainless steel, copper, titanium, nickel, aluminum, aluminum alloy panels.etc. |
||||||
| Metal Surface | PVC coated, sprayed, plastic-coated, hot-dipped galvanized, electro galvanized, etc. | ||||||
| Hole shape |
Diamond, square ,Hexagonal Or any other special shape can be manufactured as per demand. |
||||||
|
Mesh thickness(mm) |
distance short(mm) |
distance long(mm) |
strip (mm) |
width (m) |
length (m) |
weight (kg/m2) |
|
| 0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 | |
| 0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 | |
| 0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 | |
| 0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 | |
| 1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 | |
| 1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 | |
| 1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 | |
| 1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 | |
| 1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 | |
| 1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 | |
| 2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 | |
| 2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 | |
| 3 | 40 | 80 | 3.8 | 2 | 4 | 5 | |
| 4 | 50 | 100 | 4 | 2 | 2 | 11.15 | |
| 4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 | |
| 5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 | |
| 6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 | |
| 8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 | |
4. Feature Advantage
The mesh is formed from a single piece of metal;
* The process is not wasteful of material;
* Higher strength-to-weight ratio than sheet metal;
* Anti-slip surface;
* Excludes and retains simultaneously;
* Premium reinforcement properties;
* Practical and effective screening;
* High efficient conductor;
* Super corrosion resistance.
5. Competitive Advantage
1). Small sample is free.
2). According to the different customer need to customize logo.
3). According to the color of the customers like to customize.
4). We have full stock, and can deliver within short time.
5). Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
We have rich experience of design, manufacture and sell solar water heater, we cherish every order from our honor.6.Products pictures
