ISO9001 / CE 1 Inch Ball Valves Stainless Steel 304 Bsp FF Threaded
Price:
USD 6.51-6.94 dollars
MOQ:
10
Delivery Time:
40 days
Product Description
ISO9001 1 Inch Ball Valves Stainless Steel 304 Bsp Mm Threaded
Stainless steel mini ball valves are mainly made from Stainless steel 304 or 316 material, other stainless steel material are also available.
The feature and fuction is better than brass or carbon steel products.
The shape, material and color can be customized. There are MM threaded type and MF threaded type. The handle have red, blue colors for
choice. The handle are made of plastic or steel. There are NPT, BSP, BSPT threads.
For special size requirements we can also modify according to the needs.
The working pressure is 1000 PSI, WOG.
Material and specification
| Item | ITEM | Material |
| 1 | O-RING | viton |
| 2 | STEM | 304 |
| 3 | BOLT | 304 |
| 4 | LEVER | Aluminum alloy |
| 5 | BODY | CF8M |
| 6 |
CAP |
CF8M |
| 7 | BALL SEAT(A) | R-PTFE |
| 8 | BALL | CF8M |
| 9 | BALL SEAT(B) | R-PTFE |
| 10 | THRUST WASHER | PTFE |
| SIZE | 1/4" | 3/8" | 1/2" | 3/4" | 1" |
| D | 8 | 8 | 9.2 | 12.5 | 15 |
| L | 50 | 50 | 58 | 70 | 83 |
| H | 26.5 | 26.5 | 28.3 | 31.5 | 34 |
| W | 22.8 | 22.8 | 22.8 | 22.8 | 22.8 |
| S | 21 | 21 | 25 | 31 | 38 |
 |
|
