Water Pump Motor single phase 115VAC 60Hz 500W, thermal protected with foot support

Applications:

This range of single phase ac motors can be widely applied to pumps, textile machinery, small agriculture machinery, and big washing machines.

Features:
1. Power include 0.75HP, 1HP and 1.5HP
2. Designed for swimming pool pump, water pump.
3. High efficiency
4. AMB: 50°C
5. OEM available

Insulastion Class B single phase ac induction motor / 1HP electric motor

1. The working voltage has options of either 115/127VAC or 220/230VAC, and the maximum output power can reach 1HP.

2. High quality copper windings, ball bearing and centrifugal switches enable our single phase AC motors to run smoothly with less vibration and noise.

3. Ventilation holes in the housing to help the complete motor with the decline of temp. rise.

4. With a help of the extended shaft, the foot mounting is offered for a perfect fit with the final applications.

Motor Performance:

Rated Voltage: 115VAC/60Hz

Rated Power:  1/4HP

Rated Current: 3.5A

Rated Speed: 1725RPM

Power cords and shaft can be customized per your requirements, for more details, please feel free to contact us today!
