BA 316 Stainless Steel Strip / SS Coil DIN 1.4401 For Building Material
316 0.05 - 2.0mm Thickness Stainless Steel Strip DIN 1.4401 BA For Building Material
XINFUTIAN inventory includes 316/316L (UNS S31600 / S31603), in sheet, sheet coil, plate, plate coil, bar, structural and tubular products. Generally, this grade is dual-certified to meet both 316 and 316L. Alloy 316/316L is ideally suited for applications requiring corrosion resistance superior to Type 304 and has good elevated temperature strength.
1. Products Details
| Commodity | 300 Series 316 Stainless Steel Strip |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.3mm-25mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film. |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton |
2. Chemical Properties:
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 (S31600) |
0.08 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316L (S31603) |
0.03 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
Mechanical Properties:
| Grade | Tensile Strength ksi (min) |
Yield Strength 0.2% ksi (min) |
Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| 316 (S31600) |
75 | 30 | 40 | 217 | 95 |
| 316L (S31603) |
70 | 25 | 40 | 217 | 95 |
316 standards
CHINA:06Cr17Ni12Mo2
ASTM/ASME: UNS S31600
AFNOR: Z 6 CND 17-11
DIN: 1.4401
3. Resistance
Corrosion Resistance:
1) Generally more resistant than 304 in range of atmospheric environments and many corrosive media due to the increased chromium and molybdenum content.
2) Subject to pitting and crevice corrosion in warm chloride environments, and to stress corrosion cracking above about 122°F (50°C).
3) Usually regarded as the “marine grade stainless steel” – but is not resistant to warm sea water.
Heat Resistance:
1) Good oxidation resistance in intermittent service to 1600°F (870°C) and in continuous service to 1700°F (925°C)
2) Grade 316L is more resistant to carbide precipitation.
4. Applications:
Food preparation equipment, especially in chloride environments,Laboratory benches and equipment
Rubber, plastics, pulp & paper machinery ,Pollution control equipment
Boat fittings, value and pump trim,Heat exchangers,Pharmaceutical and textile industries
5. Sales points and Advantages:
- We ues the first grade material in China.”Quality is our culture”
- Good Services, adhere to the principle of customer first .
- Any special size can be customed ,and the price can be discussed.
- Good package, Pallets with waterproof or as customers' demands .
- Laser cutting, Water cutting and High accuracy are available.
- Surface finished: 2B, BA, mirror (8K), HL .
- Delivery fast , 5-7 working days after receiving the 30% deposit (at warehourse)
- Your problem is our probem.
