Large - Diameter Brushed Stainless Steel Welded Pipe 316 Wall Thickness
Price:
Negotiation
MOQ:
1 ton
Delivery Time:
5-7 working days
Brand:
XINFUTIAN
Product Description
Large Diameter Welded Brushed Stainless Steel Pipe 316 Wall Thickness
The 300 series stainless steels are classified as austenitic and are hardenable only by cold working methods. These grades of stainless have approximately 18% to 30% chromium and 6% to 20% nickel as their major alloying additions. This series of stainless steel alloys are known to resist corrosion while maintaining their strength at high temperatures. While the 304 grade is the most widely used alloy of all stainless steels, the 300 series grades are inventoried in stainless steel plate, sheet, bar, pipe, tube and fittings and much more.
Size of Stainless steel pipe
|
Normal Pipe Size
|
Outside Diameter
|
|
|||||||
|
NPS
|
DN
|
OD
|
|
SCH10s
|
SCH40s
|
STD
|
SCH40
|
XS
|
SCH80s
|
|
1/8
|
6
|
10.3
|
-
|
1.24
|
1.73
|
1.73
|
1.73
|
2.41
|
2.41
|
|
1/4
|
8
|
13.7
|
-
|
1.65
|
2.24
|
2.24
|
2.24
|
3.02
|
3.02
|
|
3/8
|
10
|
17.1
|
-
|
1.65
|
2.31
|
2.31
|
2.31
|
3.2
|
3.2
|
|
1/2
|
15
|
21.3
|
1.65
|
2.11
|
2.77
|
2.77
|
2.77
|
3.73
|
3.73
|
|
3/4
|
20
|
26.7
|
1.65
|
2.11
|
2.87
|
2.87
|
2.87
|
3.91
|
3.91
|
|
1
|
25
|
33.4
|
1.65
|
2.77
|
3.38
|
3.38
|
3.38
|
4.55
|
4.55
|
|
1 1/4
|
32
|
42.2
|
1.65
|
2.77
|
3.53
|
3.53
|
3.53
|
4.85
|
4.85
|
|
1 1/2
|
40
|
48.3
|
1.65
|
2.77
|
3.68
|
3.68
|
3.68
|
5.08
|
5.08
|
|
2
|
50
|
60.3
|
1.65
|
2.77
|
3.91
|
3.91
|
3.91
|
5.54
|
5.54
|
|
2 1/2
|
65
|
73
|
2.11
|
3.05
|
5.16
|
5.16
|
5.16
|
7.01
|
7.01
|
|
3
|
80
|
88.9
|
2.11
|
3.05
|
5.49
|
5.49
|
5.49
|
7.62
|
7.62
|
|
3 1/2
|
90
|
101.6
|
2.11
|
3.05
|
5.74
|
5.74
|
5.74
|
8.08
|
8.08
|
|
4
|
100
|
114.3
|
2.11
|
3.05
|
6.02
|
6.02
|
6.02
|
8.56
|
8.56
|
|
5
|
125
|
141.3
|
2.77
|
3.4
|
6.55
|
6.55
|
6.55
|
9.53
|
9.53
|
|
6
|
150
|
168.3
|
2.77
|
3.4
|
7.11
|
7.11
|
7.11
|
10.97
|
10.97
|
316 stainless steel pipe is a kind of hollow long round steel, which is widely used in petroleum, chemical industry, medical treatment, food, light industry, mechanical instrument and other industrial transportation pipes and mechanical structural components. In addition, bending, torsional strength of the same weight, so it is also widely used in the manufacture of mechanical parts and engineering structures. Also commonly used for the production of conventional weapons, barrels, shells, etc.
1. Grade:TP304 TP304L TP316L TP317L TP310S 904L 2205 2507
2. Size:19-720MM
3. Standard: ASTM A312 ASTM A213 ASTM A269
4. Certification: ISO9001, SGS
|
Product Name
|
Stainless Steel welded Pipes
|
|
Standard
|
ASTM A312 ASTM A213 ASTM A269
|
|
Material
|
Stainless Steel
|
|
Grade
|
TP304 TP304L TP316LTP316 Ti TP317L TP310S 904L 2205 2507
|
|
Size
|
19-720MM
|
|
Brande
|
"DONGFENG"
|
|
Technology
|
Hot rolling or Cold drawing
|
|
Used
|
Petroleurn/Chemical /Natgas/Building
|
Package
