Ferrite 440C 5mm Prime Hot Rolled Steel Panels Thickness 5mm And 10mm
Ferrite 440C 5mm Prime Stainless Steel Sheet Thickness 5mm 10mm
Grade:400 Series 440c
Thickness: 3-60mm
Width: 1500,1800,1000mm or as customzied
Length:3000,6000,2000 or as customzied
Tolerance: Thickness: ±0.02mm Length: ± 5mm
Brand : BAOSTEEL,TISCO,ZPSS
Standard: ISO,ASTM,SUS,GB
Surface:NO1
Place of origin: China (mainland)
Payment terms : L/C at sight or 30% TT as deposit
Composition
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|---|---|---|---|---|---|---|---|---|---|---|
| 440C |
min. max. |
0.95 1.20 |
- 1.00 |
- 1.00 |
- 0.040 |
- 0.030 |
16.00 18.00 |
- 0.75 |
- | - |
Physical Properties
|
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion (mm/m/°C) |
Thermal Conductivity(W/m.K) |
Specific Heat |
Electrical Resistivity (nW.m) |
|||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C | 0-200°C | 0-600°C | at 100°C | at 500°C | |||||
| 440 C | 7650 | 200 | 10.1 | 10.3 | 11.7 | 24.2 | - | 460 | 600 |
2. Applications
A.hard disk, needle, battery terminal, diamond cutting disc,
B. Chemical or medical industry, mechanical construction, sanitary equipment, C.furnishing, automobile industry, electrical appliance, C.petroleum industry and other related fields. Strip is specially applied in making kitchenware parts,electronic parts, piston wreath, and engine gasket....
Grade 440C stainless steel is a high carbon martensitic stainless steel. It has high strength, moderate corrosion resistance, and good hardness and wear resistance. Grade 440C is capable of attaining, after heat treatment, the highest strength, hardness and wear resistance of all the stainless alloys. Its very high carbon content is responsible for these characteristics, which make 440C particularly suited to such applications as ball bearings and valve parts.
3. Use cutting machine to produce coil to sheet .
