316l 5 Inch Ss Welded Pipe 4mm 45mm Cold Rolled Stainless Steel Tubing
316l 5 inch stainless steel Welded Tube 4mm ss welded steel pipe 45mm
Product details
| Type | Welded,Duplex |
| Surface | 180G, 320G Satin / Hairline (Matt Finish, Brush, Dull Finish |
| Certification | DNV,NK,LR,ABS |
| Ends | Beveled or plain end, square cut, burr free ,Plastic Cap at Both end |
| Technology | Cold/hot rolled,cold drawn |
| Surface Protect | High strength PVC bag |
| Steel Grade | 201,202,301,303,304,304L,310,316,316L,321,410,420,430,431 |
| Application | oil and gas,boiler,heat exchange,handrial |
| Tolerance | Thickness± 0.02 mm |
| Service | Free sample Third Party Test |
| Product Keywords | 5 inch stainless pipe,4mm stainless steel tube,45mm stainless steel tube |
|
Chemical Composition of Material |
Material
Composition |
201 | 202 | 304 | 316 | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.08 | ≤0.12 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 16-18 | 17-19 | 18-20 | 16-18 | 16-18 | |
| N | 3.5-5.5 | 4-6 | 8-10.5 | 10-14 | ||
| Mo | 2.0-3.0 | |||||
|
Mechanical Property |
Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <253 | <253 | <200 | <200 | ||
Q: How long is your delivery time?
A: It is according to quantity. Generally it is 30 days.
Q: Can you provide us sample, is it free or need to pay?
A: If you don’t need to print your logo or other artwork on the products, we will not charge any cost, just tell us your freight collect account like Fedex, DHL, TNT. If you don’t have, we need to charge Express fee properly.
Q: Can I get your best price?
A: Our goal is to provide you the best price with great quality assured in a long run. Please leave your contact information for the best quotations, we will get back to you with the best solutions as soon as we can.
