4 Inch Seamless Stainless Steel Tubes , Stainless Steel Polished Pipe
4 Inch Seamless Stainless Steel Tubes , Stainless Steel Polished Pipe
Seamless Stainless Steel Tubes Introduction
Incoloy Alloy 800H/800HT are a controlled composition alloy, used in applications that need high temperature creeping resistance. They offer good resistance in the variety of acidic and sulfur containing media. The blend of mechanical and thermal processing enables Nickel 800H/HT to tolerate higher stresses than those of traditional alloys.
Seamless Stainless Steel Tubes Key Features:
- Incoloy 800H/HT offers enhanced high temperature creeping resistance
- Higher strength than Incoloy 800 grade
- Stress cracking resistance up to 1100oF
- Great resistance to carburizing, oxidizing and nitriding media.
Seamless Stainless Steel Tubes Parameters
| NO | EN | ASTM/UNS | C | N | Cr | Ni | Mo | other |
| 1 | 1.4301 | 304 | 0.04 | 18.1 | 8.3 | |||
| 2 | 1.4307 | 304L | 0.02 | 18.1 | 8.3 | |||
| 3 | 1.4541 | 321 | 0.04 | 17.3 | 9.1 | Ti0.24 | ||
| 4 | 1.4550 | 347 | 0.05 | 17.5 | 9.5 | Nb0.012 | ||
| 5 | 1.4401 | 316 S31608 |
0.04 | 17.2 | 10.2 | 2.1 | ||
| 6 | 1.4404 | 316L S31603 |
0.02 | 17.2 | 10.2 | 2.1 | ||
| 7 | 1.4406 | 316LN | 0.02 | 0.14 | 17.2 | 10.3 | 2.1 | |
| 8 | 1.4429 | S31653 | 0.02 | 0.14 | 17.3 | 12.5 | 2.6 | |
| 9 | 1.4571 | 316Ti S31635 |
0.04 | 17 | 10.6 | 2.1 | Ti0.30 | |
| 10 | 1.4438 | 317L S31703 |
0.02 | 18.2 | 13.5 | 3.1 | ||
| 11 | 1.4439 | 317LMN | 0.02 | 0.14 | 17.8 | 12.6 | 4.1 | |
| 12 | 1.4435 | 316LMOD 724L |
0.02 | 0.06 | 17.3 | 13.2 | 2.6 | |
| 13 | 1.4539 | 904L N08904 |
0.01 | 20 | 25 | 4.3 | 1.5Cu | |
| 14 | 1.4547 | S31254 254SMO |
0.01 | 0.02 | 20 | 18 | 6.1 | Cu 0.8-1.0 |
| 15 | 1.4529 | N08926 Alloy25-6mo |
0.02 | 0.15 | 20 | 25 | 6.5 | 1.0Cu |
| 16 | 1.4652 | S32654 654SMO |
0.01 | 0.45 | 23 | 21 | 7 | Mn2-4-Cu 0.3-0.6 |
| 17 | 1.4162 | S32101 LDX2101 |
0.03 | 0.22 | 21.5 | 1.5 | 0.3 | Mn 4-6-Cu 0.1-0.8 |
| 18 | 1.4362 | S32304 SAF2304 |
0.02 | 0.1 | 23 | 4.8 | 0.3 | |
| 19 | 1.4462 | 2205 S32205 S31803 |
0.02 | 0.16 | 22.5 | 5.7 | 3.0 | |
| 20 | 1.4410 | S32750 SAF2507 |
0.02 | 0.27 | 25 | 7 | 4 | |
| 21 | 1.4501 | S32760 | 0.02 | 0.27 | 25.4 | 6.9 | 3.5 | W 0.5-1.0-Cu0.5-1.0 |
| 22 | 1.4948 | 304H | 0.05 | 18.1 | 8.3 | |||
| 23 | 1.4878 | 321H S32169 S32109 |
0.05 | 17.3 | 9 | TI0.2-0.7 | ||
| 24 | 1.4818 | S30415 153MA |
0.15 | 0.05 | 18.5 | 9.5 | Si1-2-Ce 0.03-0.08 | |
| 25 | 1.4833 | 309S S30908 |
0.06 | 22.8 | 12.6 | |||
| 26 | 1.4835 | 30815 253MA |
0.09 | 0.17 | 21 | 11 | Si1.4-2.0Ce 0.03-0.08 | |
| 27 | 1.4845 | 310S S31008 |
0.05 | 25 | 20 | |||
| 28 | 1.4542 | 630 | 0.07 | 16 | 4.8 | Cu3.0-5.0-Nb0.15-0.45 | ||
Seamless Stainless Steel Tubes Applications
Alloy 800H/HT are commonly used in applications that include high temperature corrosive media such as in Ethylene Pyrolysis, hydrocarbon cracking, furnaces for vinyl chloride diphenol and acetic acid, valves, fittings and other fixtures. They are used in power production, superheater, petrochemical industries, heat processing retorts, muffles jigs, baskets, trays, components, refineries, tubings , electric range heating-element enclosing, ammonia effluent coolers, extruded tubing
