Natural Surface Hot Rolled Stainless Steel Sheet 304 Grade 3mm-120mm
Natural Surface Hot Rolled Stainless Steel Sheet 304 Grade 3mm-120mm
Hot Rolled Stainless Steel Sheet Application
Building/outside material (roof, wall material) industrial/commercial/residential
Hot Rolled Stainless Steel Sheet Details
| Commodity | 300 Series Stainless Steel Plate |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 3mm-120mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1 |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton according to products |
Hot Rolled Stainless Steel Sheet Chemical Properties:
C: ≤0.08 ,Si:≤1.0 ,Mn: ≤2.0 ,Cr:18.0～20.0 ,Ni: 8.0～10.0,S: ≤0.03 ,P: ≤0.045
Hot Rolled Stainless Steel Sheet Pysical properties:
| Tensile strength σb (MPa |
≥ 520 |
Specific heat capacity(0 ~ 100 ℃, KJ kgK) |
0.50 |
| Conditions yield strength |
σ0.2 (MPa) ≥ 205 |
Thermal conductivity (W m. K) |
(100 ℃), 16.3 21.5 (500 ℃) |
| Elongation δ5 (%) |
≥40 |
The linear expansion coefficient k. |
(0 ~ 100 ℃), 17.2 (0 ~ 500 ℃) of 18.4 |
| Section shrinkage ψ (%) |
≥ 60 |
Resistivity (20 ℃, 10 Ω m.) |
0.73 |
| Hardness |
≤ 187HB; ≤ 90HRB; ≤ 200HV |
The longitudinal elastic modulus (20 ℃, KN/mm) | 193 |
| Melting point (℃) |
1398 ~ 1454 |
Specific heat capacity | 0.50 |
Hot Rolled Stainless Steel Sheet Processing
Mostly Stainless steel sheet cut from stainless steel coil, but according to the thickness.If thickness is very thick, it will be sheets directly. Below are some steps of sheets process.
1. GRINDING
Grinding finish, also called brushed, directional or satin finish. coil or sheet...
2. POLISHING
polished stainless steel sheet uses grinding fluid to polish by polishing equipment on stainless steel ..
3. PVD COLOR COATING
PVD means Physical Vapor Deposition,working in vacuum condiction.....
4. ETCHING
Etching is corrode different kinds of patterns on stainless steel surfaces by chemical methods.
5. EMBOSSING
It is physical rolling on the stainless steel surface, pattern comes from metal roller....
Hot Rolled Stainless Steel Sheet Package
| MOQ | 1 Ton |
| Price Term | FOB CIF CNF |
| Payment | L/C at sight or 30% TT as deposit |
| Delivery Time | 5-10 days after receiving deposit by T/T or L/C. |
| Sample | Samples free and express charges bear by you |
Standard export package with Kraft paper with wooded trays or as required,containers sizes as follows
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
