ASTM JIS SUS Stainless Steel Mirror Finish Sheet , Duplex Hot Rolled Steel Plate
ASTM JIS SUS Stainless Steel Mirror Finish Sheet , Duplex Hot Rolled Steel Plate
1. Stainless Steel Mirror Finish Sheet Details
| Standard: | ASTM A240,ASME SA240,AMS 5524/5507 |
| Thickness: | 0.3 ~ 12.0mm |
| Width Range: | 4'*8ft',4'*10ft',1000*2000mm,1500x3000mm etc |
| Brand name: | TISCO, ZPSS, BAOSTEEL, JISCO |
| Technique: | Cold Rolled ,Hot rolled |
| Forms : | Foils, Shim Sheet, Rolls, Perforated Sheet, Chequered Plate. |
| Applications | Pulp and Paper Textiles Water Treatment |
2. Stainless Steel Mirror Finish Sheet Chemical Properties
| Garde | (C)% | (Si)% | (Mn) % | (Cr) | (N) | (P) | (S) | (Ni) | Cu |
| 201 | ≤0.15 | ≤0.75 | 5.5～7.50 | 16.0～18.0 | ≤0.25 | ≤0.060 | 3.50-5.50% | 3.50-5.50% | half 0.8% higher 1.5% |
Pysical properties:
| Tensile strength σb (MPa): | Conditions yield strength | Elongation δ5 (%) | Hardness |
| 520 | 275 | 55-60% | ≤ 183HB; ≤ 90HRB; ≤ 200HV |
3. Stainless Steel Mirror Finish Sheet Surface
|
|
|
Characteristics | Applications |
| No. 1 | 3.0mm~150.0mm | Finished by hot-rolling, annealing and pickling, characterized by white pickled surface | Chemical industry equipment,Industrial tanks |
| BA | 0.5mm~30.0mm | Bright heat treatment after cold rolling | Kitchen utensil, kitchen ware,architectural purpose |
| No.4(Bright Annealed) | 0.4mm~3.0mm | Polishing with No. 150 to No.180 mesh abrasives | Milk & Food processing acilities, Hospital Equipment, Bath-tub |
| HL(Hair Line) | 0.4mm~3.0mm | Finished by continuous linear polishing | Architectural purposes, escalators, |
| 8k | 0.5mm~30.0mm | Shinning like a mirror | Building construction |
4. History of 201 Stainless Steel
5. Processing of Stainless Steel Sheet
Mostly Stainless steel sheet cut from stainless steel coil ,but according to the thickness.If thickness is very thick ,it will be sheets directly.Below are some steps of sheets process.
1. GRINDING
Grinding finish, also called brushed, directional or satin finish. coil or sheet...
2. POLISHING
polished stainless steel sheet uses grinding fluid to polish by polishing equipment on stainless steel ..
3. PVD COLOR COATING
PVD means Physical Vapor Deposition,working in vacuum condiction.....
4. ETCHING
Etching is corrode different kinds of patterns on stainless steel surfaces by chemical methods.
5. EMBOSSING
It is physical rolling on the stainless steel surface, pattern comes from metal roller....
6. Package
|
1, Sheets covered with wooden plate for protection in transportation. |
Stainless Steel Mirror Finish Sheet Pictures
