Thin Hot Rolled Stainless Steel Sheet 1000mm,1219mm,1250mm,1500mm
Thin Hot Rolled Stainless Steel Sheet 1000mm,1219mm,1250mm,1500mm
1. Hot Rolled Stainless Steel Sheet Details
| ITEM | Stainless Steel Sheet/Plates |
| Size | Thickness 0.01mm-3.0mm or customized;Width:500-1500mm or customize |
| Material |
201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430 .410.440.904Lect. Or Customized |
| Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
| Surface | 2B.NO.1.,NO.4,HL,BA,BK Or customized; |
| Application |
Foodstuff, Gas, metallurgy, biology, electron, chemical, petroleum, boiler, nuclear energy, Medical equipment, fertilizer etc |
| Package | Standard export sea-worthy packing or customized |
| Lead Time | 7-15 days after deposit |
| Payment | TT/LC |
| Sample | we could offer the sample for free charge but do not pay the cost of freight. |
2. Chemical Properties:
C: ≤0.08 ,Si:≤1.0 ,Mn: ≤2.0 ,Cr:18.0～20.0 ,Ni: 8.0～10.0,S: ≤0.03 ,P: ≤0.045
Pysical properties:
| Tensile strength σb (MPa |
≥ 520 |
Specific heat capacity(0 ~ 100 ℃, KJ kgK) |
0.50 |
| Conditions yield strength |
σ0.2 (MPa) ≥ 205 |
Thermal conductivity (W m. K) |
(100 ℃), 16.3 21.5 (500 ℃) |
| Elongation δ5 (%) |
≥40 |
The linear expansion coefficient k. |
(0 ~ 100 ℃), 17.2 (0 ~ 500 ℃) of 18.4 |
| Section shrinkage ψ (%) |
≥ 60 |
Resistivity (20 ℃, 10 Ω m.) |
0.73 |
| Hardness |
≤ 187HB; ≤ 90HRB; ≤ 200HV |
The longitudinal elastic modulus (20 ℃, KN/mm) | 193 |
| Melting point (℃) |
1398 ~ 1454 |
Specific heat capacity | 0.50 |
3. Hot Rolled Stainless Steel Sheet Applications:
Food preparation equipment, especially in chloride environments
Chemical processing, equipment
Laboratory benches and equipment
Rubber, plastics, pulp & paper machinery
Pollution control equipment
Boat fittings, value and pump trim
4. Processing
Mostly Stainless steel sheet cut from stainless steel coil, but according to the thickness.If thickness is very thick, it will be sheets directly. Below are some steps of sheets process.
1. GRINDING
Grinding finish, also called brushed, directional or satin finish. coil or sheet...
2. POLISHING
polished stainless steel sheet uses grinding fluid to polish by polishing equipment on stainless steel ..
3. PVD COLOR COATING
PVD means Physical Vapor Deposition,working in vacuum condiction.....
4. ETCHING
Etching is corrode different kinds of patterns on stainless steel surfaces by chemical methods.
5. EMBOSSING
It is physical rolling on the stainless steel surface, pattern comes from metal roller....
5. Package
| MOQ | 1 Ton |
| Price Term | FOB CIF CNF |
| Payment | L/C at sight or 30% TT as deposit |
| Delivery Time | 5-10 days after receiving deposit by T/T or L/C. |
| Sample | Samples free and express charges bear by you |
Standard export package with Kraft paper with wooded trays or as required,containers sizes as follows
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
