Automatic Carbon Steel Tube Mill 50M/Min 4.5mm
| Product Name | Welded Pipe Mill Green Color Max Speed 50 M / Min Thickness 4.5mm Automatic Tube Mill Line |
| After-sales Service | Engineers available to service machinery overseas |
| Pipe Material | Carbon Steel |
| Voltage | 380V |
| Power | 300KW |
| Speed | 50m/min |
| Pipe Shape | Round, Square & Rectangular |
| Round Pipe Diameter | 25-60mm |
| Warranty | 1 year |
The HG60x8 high-frequency pipe mill line is designed for processing electric welding pipes with diameters of Φ25-Φ60mm and thicknesses of 1.0-4.5mm. This automated system can produce various pipe shapes while significantly reducing labor requirements.
| Model | Thickness (mm) | Specification (mm) | Speed (m/min) | Main Engine (kw) | Power (kw) |
|---|---|---|---|---|---|
| H20 | 0.3-1 | 8-20 | 30-120 | 55 | 60 |
| H32 | 0.3-2.0 | 12-32 | 30-120 | 75 | 100 |
| H50 | 0.8-2.5 | 16-50 | 30-110 | 110 | 150 |
| H60 | 0.8-3 | 20-60 | 30-100 | 132 | 200 |
| H76 | 1-3 | 12-76 | 30-100 | 320 | 250 |
| H89 | 1-4 | 32-89 | 30-80 | 350 | 300 |
| HG114 | 1.5-5 | 45-114 | 30-60 | 400 | 300 |
| HG165 | 3-7 | 60-165 | 30-50 | 600 | 400 |
| HG219 | 4-8 | 114-219 | 20-40 | 800 | 500 |
| HG273 | 4-10 | 114-273 | 15-30 | 1000 | 600 |
| HG325 | 4-12 | 165-325 | 10-30 | 1200 | 600 |
| HG426 | 4-16 | 165-426 | 8-25 | 1400 | 800 |
| HG508 | 4-20 | 219-508 | 8-20 | 2000 | 1000 |
- Installation & Training: Our engineers will install the equipment and train your workers in proper operation
- Warranty Coverage: 1-year quality guarantee with lifetime repair support
- Pre-Sale Services: Workshop design and production output planning
- After-Sale Support: Ongoing technical assistance from skilled engineers
- Extended Engineering Support: Option for engineers to work onsite for months to optimize production
- Project Design: Complete project planning for stainless steel or carbon steel pipe production
- Logistics: We handle all loading and shipping arrangements
1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.
2.) Warranty Team
One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.
3.) We supply the pre-sell and after-sell service.
pre-sell service: workshop design, and production output design
after-sell service: installation and training, and the skilled engineer for working.
4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.
5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.
6.) We will be responsible for the loading and shipping
Q1: Are you manufacturer or trading company?
A1: we are manufactuer , more than 20 years experience.
Q2: What is the max size of pipe you have even produce?
A2: Max φ630mm
Q3:Can I visit your customer machine line?
A3: Yes, but I need to get agreement from my customer firslty.
Q4: what is your machine advantages?
A4:Contain Full automatic, Direct forming square, Share rollers. Fast change system
Q5:How I can get the quotation?
A5:Please send your requires of pipe size , thickness to us.
