10-50mm Steel Pipes CNC Automatic Pipe Mill Machine
| Attribute | Value |
|---|---|
| Product Name | CNC Automatic Pipe Mill Machine for Structural Round Pipe |
| Pipe Diameter | 10-50mm |
| Product Speed | Max 90m/min |
| Material | Steel pipe, Stainless pipe |
| Special Requirement | Can be designed according to customer specifications |
| Color | Blue |
- Professional manufacturer with 12 years experience in metal pipe cutting machines
- Our intelligent cutting machines offer superior precision and labor-saving operation
- Innovative research and development for continuous product improvement
- Low-speed rotation high-speed hacksaw for clean cuts with no burrs or deformation
- Servo feeding with 0.20mm accuracy and customizable feed length up to 1 meter
- PLC control with easy operation via touch screen interface
- Programmable for multiple cutting lengths and batch quantities
- Automatic material detection with shutdown and alarm systems
- Advanced cooling system extends saw blade durability
- Lifting function minimizes pipe and mold friction
- Fast cycle time of 6-7 seconds per piece (adjustable based on pipe size)
- Vertical chute cutting ensures stability during operation
- Automatic leftover material removal eliminates secondary processing
- 10-inch high-resolution LCD with real-time 3D cutting animation
| Steel Pipe Material | Q235 |
| Diameter Range | Round Ø48-Ø152mm, Square 120x120mm |
| Thickness | 4-5mm |
| Production Line Speed | 50-70m/min |
| Cutting Length | 4000-10000mm |
| Cutting Accuracy | ≤±3mm |
| End Burrs | ≤0.2mm |
- 20 years of manufacturing experience ensuring reliable quality
- BV certified with onsite inspection
- Nationally certified for high credibility
- Independent import/export authority
- Short delivery times guaranteed
| Model | Diameter Range | Thickness Range | Max. Speed | Motor | Saw Blade Dia. | Clamping Type |
|---|---|---|---|---|---|---|
| CS - 32 | 12~38 | 0.4~2.0 | 120 | YASKAWA / SIEMEMS | 350 | Pneumatic |
| CS - 50 | 20~63.5 | 0.6~2.0 | 100 | YASKAWA / SIEMEMS | 400 | Pneumatic/Hydraulic |
| CS - 60 | 25~76 | 0.8~3.0 | 80 | YASKAWA / SIEMEMS | 450 | Pneumatic/Hydraulic |
| CS - 76 | 25~76 | 0.8~4.0 | 80 | YASKAWA / SIEMEMS | 450 | Hydraulic |
| CS - 114 | 50~114 | 1.2~5.0 | 60 | YASKAWA / SIEMEMS | 600 | Hydraulic |
1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.
2.) Warranty Team
One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.
3.) We supply the pre-sell and after-sell service.
pre-sell service: workshop design, and production output design
after-sell service: installation and training, and the skilled engineer for working.
4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.
5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.
6.) We will be responsible for the loading and shipping
- Onsite installation and operator training by our engineers
- One year quality guarantee with lifetime repair service
- Comprehensive pre-sales and after-sales support
- Option for extended engineer support (several months to 1 year)
- Complete project design for stainless/carbon steel pipe production
- Responsible for loading and shipping arrangements
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
