PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
Plastic PC / SWP series waste pvc pipe crusher machine prices
Feature:
Crusher for plastic pipe blades material is SKD-11
Blade base and blade can be disassembly, it is easy to clean and maintenance .
Push material feeding system adopt hydraulic ways, it's running very stably .
Main axis is drived by gearbox , it's running very stably ,low noise and strong power .
Rotating blade adopt the V design , it can decrease the noise and energy consumption .
Crusher for plastic pipe is controlled by PLC system,blade can rotate in opposite direction,also can automatic closed if something unexpected happened,which is advanced and safety service.
Main technical parameters:
| Model | Crushing capacity kg/hr |
Power Kw/Hp |
Into size mm |
Stationary Cutter |
Rotary Cutter | Machine Size L*W*H |
Weight Kgs |
| fld-30 | 90-120 | 2.2/3.0 | 180*160 | 2 | 9 | 500*430*900 | 250 |
| fld -50 |
100-160 | 4.0/5.0 | 290*220 | 2 | 15 | 850*620*1050 | 350 |
| fld -100 |
150-400 | 7.5/10.0 | 400*250 | 2 | 21 | 970*800*1340 | 740 |
| fld -150 |
300-600 | 11.0/15.0 | 460*300 | 2 | 24 | 1200*1100*1350 | 1000 |
| fld -200 |
500-800 | 15.0/20.0 | 515*330 | 2 | 37 | 1320*1155*1700 | 1300 |
| fld -300 |
700-1000 | 22.0/30.0 | 550*440 | 2 | 30 | 1320*1210*1800 | 1700 |
| fld -500 |
1500-1800 | 37.0/50.0 | 720*500 | 2 | 39 | 2850*1430*2180 | 3200 |
PC600 crusher
PC600 crusher control box
SWP400 Crusher
SWP400 Crusher blade
