PVC Plastic Granules Two Stage Extruder Machine For Low Smoke Free Halogen Cable
Two Stage Compunding Extruder Line for Low smoke free halogen cable material 300-500kg/h capacity of GSJ series extruders consisted of two stage components. The first stage is GSJ co-rotating twin-screw extruder, the second stage is GSJ single screw extruder. This machine first of all to realize material better compounding and shearing by twin-screw, then the single screw fulfills the task of extruding and granulating.
The scientific and advanced structure of our Two Stage Compunding Extruder Line for Low smoke free halogen cable material 300-500kg/h capacity can avoid material decomposition phenomena due to overheating. To combines the advantage of twin-screw and single screw together and complementation, likewise, propitious to every craft distribution and optimize so that making higher efficient and production capacity.
Two Stage Compunding Extruder Line for Low smoke free halogen cable material 300-500kg/h capacity detailed picture:
Two Stage Compunding Extruder Line for Low smoke free halogen cable material 300-500kg/h capacity models:
| Model | Main frame |
(kw) Motor Power |
(rpm) Rotate speed |
| GSJ-50/100 |
GS-50twin screw extruder |
37-55 | 500-600 |
|
GSD-100single screw extruder |
22-45 | 60-90 | |
| GSJ-65/150 |
GS-65 twin screw extruder |
55-75 | 500-600 |
|
GSD-150 single screw extruder |
45-55 | 60-90 | |
| GSJ-75/180 |
GS-75 twin screw extruder |
75-132 | 500-600 |
|
GSD-180 single screw extruder |
75-90 | 60-90 | |
| GSJ-95/200 |
GS-95 twin screw extruder |
250-315 | 400-500 |
|
GSD-200 single screw extruder |
90-132 | 60-90 |
